600000 Kcal Low Pressure Gas Boilera , Gas Steam Furnace 1.0MPa Pressure
600,000 kcal Low Pressure Fully Automatic Safety Low Pressure Oil Fired Gas Fired Steam Boiler
The 1 ton WNS gas steam boiler model is WNS1-1.0-Q (pressure is 1.0MPa), the specific parameters are as follows:
Rated evaporation: 1t/h
Rated steam temperature: 184 degrees C
Rated operating pressure: 1.0MPa
Inlet temperature: 20d egrees C
Fuels used: natural gas, gas, liquefied petroleum gas, biogas
Fuel consumption: natural gas 70m3/h, LPG 29m3/h, gas 168m3/h
Boiler size: 3500mm long, 1900mm wide, 2200mm high
Total power consumption: 3.3KW
Chimney diameter: 350mm
Steam outlet: 50DN
Boiler weight: 4.5 tons
Part of product parameters
| WNS0.5-1.0-YQ | 0.5t/h | 1.0Mpa | Gas/Oil | 91% | 2500*1330*1650 |
| WNS0.7-1.0-YQ | 0.7t/h | 1.0Mpa | Gas/Oil | 92% | 3330*1620*1950 |
| WNS1-1.0-YQ | 1t/h | 1.0Mpa | Gas/Oil | 94% | 3750*1700*2000 |
| WNS2-1.0-YQ | 2t/h | 1.0Mpa | Gas/Oil | 92% | 4300*1900*2400 |
| WNS3-1.0-YQ | 3t/h | 1.0Mpa | Gas/Oil | 92% | 4100*2024*2388 |
| WNS4-1.0-YQ | 4t/h | 1.0Mpa | Gas/Oil | 92% | 4845*2200*2644 |
| WNS6-1.25-YQ | 6t/h | 1.25Mpa | Gas/Oil | 93% | 5320*2230*2635 |
| WNS6-1.6-YQ | 6t/h | 1.6Mpa | Gas/Oil | 93% | 5320*2230*2635 |
| WNS10-1.6-YQ | 10t/h | 1.6Mpa | Gas/Oil | 94% | 7300*2860*3144 |
WNS1-1.0-YQ
| NO; | Name | Unit | Number | Description |
| 1 | Rated evaporation | t/h | 1 | |
| 2 | Rated working power | Mpa | 1.0 | |
| 3 | Rated outlet ℃ | ℃ | 193 | |
| 4 | Design efficiency | ％ | 92.6(Oil) | |
| 5 | Boiler heat efficiency | ％ | More than 98% | |
| 6 | Design fuels | / | Light oil,Gas | |
| 7 | Fuels LHV | MJ/kg | 42.917(Oil) | |
| MJ/Nm3 | 35.438(Gas) | |||
| 8 | Consumption of fuels | kg/h | 137.9(Oil) | |
| Nm³/h | 167.325(Gas) | |||
| 9 | Radiation heating area | m² | 8.527 | |
| Convection heating area | m² | 41.838 | ||
| GGH heating area | m² | 23.195 | ||
| 10 | Fume temperature | ℃ | 137.863(Oil) | |
| ℃ | 134.28 (Gas) | |||
| 11 | Fume temperature | ℃ | 60-80 | |
| 12 | Excess air coefficient | / | 1.15 | |
| 13 | Volume | m3 | 1 | |
| 14 | Bulk weight | kg | ||
| 15 | Bulk size | mm | 3750×1700×2000 | |
| 16 | Chimney | mm | Φ500×10000 | |
| 17 | Total power consumption | KW | Oil:13,Gas:11 | |
| 18 | Combustion model | / | Micro positive pressure | Chamber combustion |
| 19 | Boiler structure feature(Three-pass structure) | Horizontal-type chamber combustion | ||
| 20 | Control way | Full automation/Manual | ||
| 21 | Ignition way | High-tension/Electrode | ||
Our services
Pre-sale service:
We help customer choose the best boiler model according to
different requirements of various industry. Before delivery we
will provide foundation drawing, layout drawing, boiler room
layout, etc.
In-sale service:
We keep 24 hours online and keep close contacts during the
production process to ensure on time delivery with perfect
finished product.
After-sale service:
1. provide full range of original spare parts.
2. Engineers abroad installation and commissioning service is
available.
3. Our engineers will held a training for boiler workers to
ensure the safe operation.
4 . Free maintenance and repair for one year and lifelong
service.
