2t Fire Tube Gas Fired Steam Boiler Energy Conversation Horizontal Style
2t Low Pressure Energy Conversation Fully Automatic Safety Low Pressure Oil Fired Gas Fired Steam Boiler
WNS2-1.0/194/104-Q, modified gas steam boiler is to produce 2 steam tons of steam per hour, the main design fuel is natural gas, product design steam pressure is divided into 0.7, 1.0, 1.25, 1.6Mpa several grades. The gas-fired steam boiler is rated at a maximum temperature of 204 degrees C, and the remaining steam temperature is 170 degrees C, 184 degrees C, 194 degrees C. Product scants can be made according to customer requirements.
Part of product parameters
| WNS0.5-1.0-YQ | 0.5t/h | 1.0Mpa | Gas/Oil | 91% | 2500*1330*1650 |
| WNS0.7-1.0-YQ | 0.7t/h | 1.0Mpa | Gas/Oil | 92% | 3330*1620*1950 |
| WNS1-1.0-YQ | 1t/h | 1.0Mpa | Gas/Oil | 94% | 3750*1700*2000 |
| WNS2-1.0-YQ | 2t/h | 1.0Mpa | Gas/Oil | 92% | 4300*1900*2400 |
| WNS3-1.0-YQ | 3t/h | 1.0Mpa | Gas/Oil | 92% | 4100*2024*2388 |
| WNS4-1.0-YQ | 4t/h | 1.0Mpa | Gas/Oil | 92% | 4845*2200*2644 |
| WNS6-1.25-YQ | 6t/h | 1.25Mpa | Gas/Oil | 93% | 5320*2230*2635 |
| WNS6-1.6-YQ | 6t/h | 1.6Mpa | Gas/Oil | 93% | 5320*2230*2635 |
| WNS10-1.25-YQ | 10t/h | 1.25Mpa | Gas/Oil | 94% | 7300*2860*3144 |
WNS2-1.25-YQ
| NO; | Name | Unit | Number | Description |
| 1 | Rated evaporation | t/h | 2 | |
| 2 | Rated working power | Mpa | 1.25 | |
| 3 | Rated outlet ℃ | ℃ | 193 | |
| 4 | Design efficiency | ％ | 92.6(Oil) | |
| 5 | Boiler heat efficiency | ％ | More than 98% | |
| 6 | Design fuels | / | Light oil,Gas | |
| 7 | Fuels LHV | MJ/kg | 42.917(Oil) | |
| MJ/Nm3 | 35.438(Gas) | |||
| 8 | Consumption of fuels | kg/h | 137.9(Oil) | |
| Nm³/h | 167.325(Gas) | |||
| 9 | Radiation heating area | m² | 8.527 | |
| Convection heating area | m² | 41.838 | ||
| GGH heating area | m² | 23.195 | ||
| 10 | Fume temperature | ℃ | 137.863(Oil) | |
| ℃ | 134.28 (Gas) | |||
| 11 | Fume temperature | ℃ | 60-80 | |
| 12 | Excess air coefficient | / | 1.15 | |
| 13 | Volume | m3 | 5 | |
| 14 | Bulk weight | kg | 9700 | |
| 15 | Bulk size | mm | 4531×2150×2544 | |
| 16 | Chimney | mm | Φ500×10000 | |
| 17 | Total power consumption | KW | Oil:13,Gas:11 | |
| 18 | Combustion model | / | Micro positive pressure | Chamber combustion |
| 19 | Boiler structure feature(Three-pass structure) | Horizontal-type chamber combustion | ||
| 20 | Control way | Full automation/Manual | ||
| 21 | Ignition way | High-tension/Electrode | ||
Our services
Pre-sale service:
We help customer choose the best boiler model according to
different requirements of various industry. Before delivery we
will provide foundation drawing, layout drawing, boiler room
layout, etc.
In-sale service:
We keep 24 hours online and keep close contacts during the
production process to ensure on time delivery with perfect
finished product.
After-sale service:
1. provide full range of original spare parts.
2. Engineers abroad installation and commissioning service is
available.
3. Our engineers will held a training for boiler workers to
ensure the safe operation.
4 . Free maintenance and repair for one year and lifelong
service.
