Light Weight Wood Steam Boiler Automatic Feeding Saving Storage Space
Light Weight Quality Guarantee Durable Biomass Fired Wood Steam Boiler
Biomass particles, as a new type of particulate fuel, have won wide recognition for their unique advantages. Compared with traditional fuels, it not only has economic advantages but also environmental benefits, which is fully in line with the requirements of sustainable development.
First, because the shape is particles, the volume is compressed, saving storage space, but also easy to transport, reducing transportation costs.
Secondly, the combustion efficiency is high, easy to burn down, the residual carbon amount is small. Compared with coal, the volatile content is low in ignition point, easy to ignite, the density is increased, the energy density is high, the combustion duration is greatly increased, can be applied directly in coal-fired boilers.
In addition, biomass particles burn the content of harmful gases is very low, the emission of harmful gases is low, with environmental benefits. And after burning ash can also be used as potassium fertilizer directly, saving money.
Product parameters
DZS4-1.25SCI
| NO; | Name | Unit | Number | Description |
| 1 | Rated output | t/h | 4 | |
| 2 | Rated working power | Mpa | 1.25 | |
| 3 | Rated steam pressure | ℃ | 194 | |
| 4 | Heating efficiency | % | 80 | |
| 5 | Grate area | ㎡ | 5.18 | |
| 6 | Design fuels | / | Biomass,coal,rice husk... | |
| 7 | Fume temperature | ℃ | 169 | |
| 8 | Bulk size | mm | 6470×2820×3668 |
DZS6-1.25SCI
| NO; | Name | Unit | Number | Description |
| 1 | Rated output | t/h | 6 | |
| 2 | Rated working power | Mpa | 1.25 | |
| 3 | Rated steam pressure | ℃ | 194 | |
| 4 | Heating efficiency | % | 80 | |
| 5 | Grate area | ㎡ | 7.55 | |
| 6 | Design fuels | / | Biomass,coal,rice husk... | |
| 7 | Fume temperature | ℃ | 166.3 | |
| 8 | Bulk size | mm | 8244×2951×3550 |
Etc
