Large Output Commercial Hot Water Boiler , Gas Hot Water Furnace For Station
Oil Fired Gas Fired Hot Water Boiler Supply Hot Water For Station
Boiler is a kind of special equipment for heating and providing industrial use. In the domestic heating, there are mainly the provision of hot water and steam, such as domestic hot water, bath water. The industry mainly provides steam for other equipment to provide refrigeration, power and other services, such as ships, locomotives, mines and other places. Boiler working principle is complex, mainly has fuel system, smoke system, soda system and so on.
Different types of boilers also work differently. According to the size of heating and service objects can be divided into the following three categories: household boilers are mainly electric boilers (electric hot water boilers), small gas boilers, wall-mounted furnaces, etc. ;
Part of product paremeters
CWNS0.7-95/70
| NO; | Name | Unit | Number | Description |
| 1 | Rated efficiency | MW | 0.7 | |
| 2 | Water volume | M³ | 1.4 | |
| 3 | Rated outlet/inlet water temperature | ℃ | 95/70 | |
| 4 | Heating efficiency | % | 99 | |
| 5 | Output/inlet diameter | mm | DN100 | |
| 6 | Design fuels | / | Oil/Gas | |
| 7 | Blow down valve diameter | mm | DN100 | |
| 8 | Heating area(room) | ㎡ | 6000 | |
| 9 | Hot water output | M³/h | 18 | |
| 10 | Bulk size | mm | 2400×1200×1800 |
CWNS1.4-95/70
| NO; | Name | Unit | Number | Description |
| 1 | Rated efficiency | MW | 1.4 | |
| 2 | Water volume | M³ | 3.75 | |
| 3 | Rated outlet/inlet water temperature | ℃ | 95/70 | |
| 4 | Heating efficiency | % | 99 | |
| 5 | Output/inlet diameter | mm | DN125 | |
| 6 | Design fuels | / | Oil/Gas | |
| 7 | Blow down valve diameter | mm | DN125 | |
| 8 | Heating area(room) | ㎡ | 12500 | |
| 9 | Hot water output | M³/h | 36 | |
| 10 | Bulk size | mm | 2800×1700×2300 |
Pre-sale service:
We help customer choose the best boiler model according to
different requirements of various industry. Before delivery we
will provide foundation drawing, layout drawing, boiler room
layout, etc.
In-sale service:
We keep 24 hours online and keep close contacts during the
production process to ensure on time delivery with perfect
finished product.
After-sale service:
1. provide full range of original spare parts.
2. Engineers abroad installation and commissioning service is
available.
3. Our engineers will held a training for boiler workers to
ensure the safe operation.
4. Free maintenance and repair for one year and lifelong
service.
Boiler application areas
