Aluminum Alloy Industrial Automation Roll Up Door High Speed Spiral Door Safety Efficiency Wind Resistance 2.0knm2 Safety Efficiency

Aluminum Alloy Industrial Automation Roll up Door High Speed Spiral Door Safety Efficiency Wind Resistance 2.0KNm2 Safety Efficiency

Product Description:

High speed spiral doors are suitable for installation in industrial buildings, factories, warehouses, workshops, garages and other
industrial equipment exits. The new arc-shaped turbine and tensioning torque balance technology can ensure a more stable operation of the door body, can achieve automatic opening and closing of the door. and one person can easily open and close the operation.

All measurements are made indoors and each value must be measured at at least three points:
H--the height of the doorway (the distance from the ground to the top of the doorway)
B--the width of the door opening (the distance from the left edge of the door opening to the right edge)
h--Above the doorway (the distance from the top of the doorway to the ceiling) is generally reserved 900mm
b1/ b2 is the left/right lateral distance of at least 350 mm (distance from the corresponding edge of the door opening to the obstacle)
L is the depth of the room.
When measuring h, b1, b2 and L, take the smallest value as the final size.

Product Paramenters:

Our Advantages
:

1. 0.7mm thick double-layer aluminum alloy door panel, filled with high-density polyurethane foam in the middle, the total
thickness of the door panel is 45mm with a volume density of 9.6kg per square meter, and the heat insulation structure is designed.

2. Sealing Performance: There are guide rail sealing, sealing in the middle of the door panel, top sealing of the door body, and bottom sealing of the door body. Multiple seals ensure the airtightness and isolation effect inside and outside the door body.

3. The integrated transmission system of the pulley and the track balance mechanism enables the door to run lightly, smoothly and
quickly.

4. Safety System:① Infrared Safety Photoelectric sensors on the door frame sides keep the door open when an obstacle is under the high - speed door.② Bottom Safety Airbag: If an object is in the infrared blind zone during door descent and the door presses the obstacle, the door rebounds fully open to protect lower objects/pedestrians.

Packing and Shipping:

FAQ:

Q:Are you trading company or a factory?
A:We are a factory with more than 10 years of industry experience.We have a professional R&D team and we can customize exlusive according to your needs.
Q:Can you customize production according to my project drawing?
A:Of course,our professional engineers will check your project drawing to ensure that every accessory and parameter is accurate.
Q:Do you produce other products:
A:Yes,we also produce dock shelter,industry door,high speed door,high speed spiral door,transparent Aluminum sectional door,garage door,and etc.
Q:What's your MOQ?
A:It's one unit.But we have a good discount if our order more.
Q:How can I get more information about your products?
A:Welcomg to check our website,and we can also send our catalogue to you.
