Motor Operate Overhead Sectional Door Surface Finished For Warehouse
CE-Approved Industrial Sectional Overhead Vertical Door
| Applicable door opening | Maximum width 9000/Maximum height 8000 |
| Working voltage /frequency | 380v/50HZ |
| Motor power | 180W,380W |
| Thickness of door panel | 40mm,50mm |
| Heat transfer coefficient | K≤0.8/m2.K |
| Sound insulation property | 23bd |
| Applicable temperature | -40℃-50℃ |
| Resistance to wind pressure |
450N/m2(With windproof reinforcement, having resistance to wind pressure, 650N/m2 in resistance to wind pressure) |
| Operating speed | 0.2m/s |
Features:
Core material
High density polyurethane foam,40-45m3/kg
High qualified color coat steel
Thickness of door panel
40mm
Thickness of steel plate
0.4mm
Height of door panel
500mm
Max. width of door panel
≤8000mm
Size of garage door
according to customers' requirements
Color
White ,Cream,Brown,Black ,Golden ,Sliver, Gray
Pattern
Microwave ,Smooth ,Classic ,H-line ,Strips
Grain
Woodgrain ,Orange peel, Smooth
Certification
ISO-9001, CE ,RoHS ,HGS
Lighting windows
Standard size
Hardware
Hot galvanized
Opener
Belt and chain driving for your choice ,
Sectional track and integrated track for your choice
