5000*7500 MM Aluminum Roll Up Door , Industrial Roll Up Door Powder Coated Steel
Economical and efficient, the High Speed Spiral sectional door, with electromechanical drive, is designed for industrial, continuous use even under the most difficult conditions and to operate continuously with minimal maintenance.
Construction
Double-walled 220mm aluminum slats
Integral weatherseal between the aluminum slats
Heavy-duty hinge system for door panel assembly
Durable powder coated steel side columns and head console (excludes US/R models)
Extension springs in side column
Main Features:
High Speed,Automatic,security,heat preservation,durable.
Application Scope:
The industrial door is applied to the outdoor passage.
Technical Data:
| Item | Description |
| Mateiral | Aluminum Alloy Profile(PU Sandwich optional) & Transparent PVC Section |
| Thickness of Material | Double-layer Aluminum profile 0.8mm ~ 2.5mm |
| Thickness of Panel | 40mm ~ 70mm |
| Foam Density | ≥ 50kg / m3 |
| Speed | Open / Close to max : 2.5 / 0.7 m/s |
| Wind Resistance | Beaufort scale 12 (35 m / s) |
| Color: | White / Grey / Sliver / Blue / Red / Customer-tailor |
| Noise Level: | < 60dB |
| Lifting way | 90°Vertical Lift / Turbo Type / Ellipse Type |
| Max Dimension | 5000*7500 MM |
| Heat preservation | K ≤ 1.5W/(m2•K) |
| Drive System | Brake Motor or Servo Motor SEW / ABB Brake Motor, 220V 50HZ / 380V 50HZ, 0.75Kw, 1.1Kw,1.5Kw,2.2Kw |
| Control System | Inverter Type or Servo Type |
| Service Life | > 10 Years |
| Safety | 1) Photocell Sensor 2) Airbag Installed at Door Edge Bottom (BUTTERFLY Pressure Wave Sensor) |
Options
Insulated slats
Vision slats
Ventilated slats
Hood and motor covers
Classic RAL and custom color match powder coated finish
