Water Saving 35mm Double Seal Taps Valve Ceramic Cartridge
China produce good quality and price water saving 35mm double seal taps valve ceramic cartridge
35mm taps valve ceramic cartridges are mainly used in kitchen taps and bathroom taps.
Kailif ceramic cartridge have been used by many faucet and taps factory in internation market.
Kailif ceramic cartridge have been exported to Iran,Turkey,Russia,Egypt,India,Italy,Argentina.
| Min.Temperature | -23℃ | Max.Temperature | 90° |
| Lever Break Torque | ≧10N.m | Max.Turning Angle | 100° |
| Gland Nut Torque | 9-11N.m | Max.Opening Angle | 23° |
| Pressure(bar) | 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 | ||
| Average Flow Rate(L/min) | 6.5 8.2 10.1 12 14 15.6 17.3 19 20.6 22.1 | ||
| Average Flow Rate(L/min) | 10.5 12.4 14.5 16.6 18.4 20 21.7 23.4 25.1 27 | ||
| Testing Performance | |||
| Noise Level | 18-19db(A)bar with filter | noise readucer | Selectable |
| Air-Leak Test | 8bar | Ceramic Disc | Al₂O₃96% |
| Burst Test | Staic water pressure at MAX.30 bar, no deformation on cartridge | ||
| Life Test | Min.70,000 Cycles(EN817, GB1845-2014) | ||
| Cermin Disc Technical Request | ||||
| Sealing Surface Of Ceramic Disc | Hardness | 1100HV5 | Flatness | ≦0.25um |
| Surface Roughness | Ra≦0.25um | Porosity | 60-80% | |
The ceramic disc is 96% Alumina Porcelain
Plastic Handle: Material PA-6 Handle Seat: POM
Cover body for faucet ceramic cartridge Material: PBT
Each inner white box pack 50pcs
300pcs faucet ceramic cartridge pack into one cartron.
Container loading faucet valve ceramic cartridge
Q1: Why choose KAILIF Cartridge? Does it have any advantages?
A: There are 6 advantages.
(1) MUTUAL BENEFITS: We manufacture the best cartridge with the most competitive price.
(2) CUSTOMIZE: We can customize cartridge for you and also meet your demand of theShipment and Quality.
(3) OEM: (1) Your logo: Laser Printing ( over 5000PCS). (2) Packing Design (over 5000PCS).
(4) MIX ORDER: We accept mix orders, different models and small quantity orders.
(5) SHORT LEAD TIME: As Usual we will ship the order in about 15-20days. Urgent order or quick delivery order is acceptable.
(6) AFTER-SALE SERVICE: We guarantee the cartridge can work 500,000 times.
(7)The self design: We can design the product as yours idea.
Q2: Installation Comments?
A: (1) Before fixing, the dirty water, detritus should be cleaned away to avoid blocking.
(2) The faucet should be correctly connected with the hot and cold pipes. Facing the faucet, the left is connected with hot water, the other side is cold water.
(3) Examine the fixing size, don't fix it violently in order not to break the parts.
(4) Clean the surface regularly, keep clean. Don’t use the rubbing cleanser, hard cloth, steel ball, acid cleanser or soap.
Q3: Can I order one piece as a sample to test the quality?
A: Yes, We recommend you test the sample before order.
Q4: May I have your catalogue and price list for trial order in MOQ quantity?
A: All our products are on display on our website , please check the details and choose the modelsyou are interested in. The MOQ price is marked, please find it at the top of this page.
Q5: If I order big quantity, what's the good price?
A: Please send detailed enquiry to us, such as the Item Number, Quantity for each item, Quality request, Logo, Price Term, Transport method, Discharge place etc. We will make the accurate quotation to you as soon as possible.
