Fire Safety Needle Flame Test Apparatus / Flammability Test Chamber

Fire Safety Needle Flame Test Apparatus / Flammability Test Chamber ​

Advantages:

Needle flame tester used not only for low-voltage electrical appliances, power tools, machine tools, electrical instruments, household appliances, electrical, electronic equipment, lighting, electrical connections, accessories and other electrical and electronic equipment and components, components research, production and quality Departments, but also for insulating materials, engineering plastics or other solid combustible materials industry

Brief Introduction:

Needle flame tester is the needle-shaped burner by a certain size, fill the inside with a specific gas (butane), and at 45 ° angle by fixed time and certain direction to test products, Assess the fire hazard of small flames caused by fault conditions inside the equipment, depending on the test sample Whether ignited, and its ignition time and combustion Length.

Product features:

1, the unique delay exhaust system, the machine can continuously run after the exhaust ventilation which can be preset 1 ~ 3min

2, completely independent of electricity, gas design, use safely
3, military-grade explosion-proof glass
4, box with high hardness stainless steel

Technology data:

1. Accord with standard:IEC-60695,GB5169
2. Burning time adjust range:0-99.99s
3. Temperature display range:0-1200degree
4. Remainder combustion range:0~99.99s
5. Remainder time resolution rate:0.01s
6. Flame temperature resolution rate:1degree
7. Burning time Resolution rate:0.01s
8. Size:1120w*600d*1020h
9. Flame height adjust:5-45mm
10. Sustained combustion range:0~99.99s
11. Background of inner case:black(power baking varnish)

Standard configure:

1. Standard clamp
2. Flame height adjust device

Select configure:

1. high pure tetrane gas
2. flame temperature adjust device
3. other nonstandard clamp
