Small Capacity Die formed Lollipop Production Line
Small Capacity Die formed Lollipop Production Line
Products Description
1. Continuously vacuum cooker, guarantee the quality of sugar masses
2. Special forming style is better for central-filling.
3. Production capacity can be from 300 to 400kg/h.
4. Sanitary structure designed.
5. The central filler, rope sizer and former work together available.
6. Different candy shape can be made depend upon changing of the mould.
7. A better effect of cooling is available by the conveying and cooling system.
8. Lollipop can be made when the lollipop former is set instead of hard candy former.
Product Parameters
|
Model |
YT200 |
YT400 |
YT1000 |
|
Capacity |
150kg/h |
300kg/h |
600-1000kg/h |
|
Rated output speed |
500pcs/min |
1000pcs/min |
2000-4000pcs/min |
|
Max. Weight of the candy |
Shell: 7g(max)central-filling: 2g(max) |
||
|
Steam pressure |
0.5-0.8MPa |
||
|
Steam consumption |
200kgs/h |
300kgs/h |
400-600kgs/h |
|
Room temperature |
20-25℃ |
||
|
Humidity |
<55% |
||
|
Total electric power |
18kW/380V/50Hz |
30kW/380V/50Hz |
45-60kW/380V/50Hz |
|
Leight of the whole plant |
16m |
22m |
25-40m |
|
Gross weight(approx.) |
4500kg |
8000kg |
10000-15000kg |
