SF16 2/3/4/5/7/9Pins Push-Pull Self-Locking Circular Connector Waterproof Male/Female Aviation Plug
Price:
3$
MOQ:
50sets
Delivery Time:
7Days
Brand:
BETT
Product Description
Product Specification
| 参数 | 2 芯 | 3 芯 | 4 芯 | 5 芯 | 6 芯 | 7 芯 | 8 芯 |
|---|---|---|---|---|---|---|---|
| 芯数(Contacts numbers) | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
| 额定电压(Voltage rating) | 300V | 300V | 110V | 60V | 60V | 60V | 60V |
| 额定电流(Current rating) | 12A | 8A | 4A | 3A | 2A | 2A | 2A |
| 线材匹配(Cable-OD) | ≤1.5mm² | ≤1.0mm² | ≤0.5mm² | ≤0.3mm² | ≤0.2mm² | ≤0.2mm² | ≤0.2mm² |
| 线材外径(Cable OD) | — | — | — | 5mm—12mm | — | — | — |
| 可插拔次数 | — | — | — | 3000 mating cycles | — | — | — |
| 工作温度(Operating rating) | — | — | — | -40°C - +105°C | — | — | — |
| 防水等级(Waterproof level) | — | — | — | ip68 | — | — | — |
