Bett M6 Mini Waterproof Connector IP65 Male Female For Bike / Light
Bett M6 Mini waterproof connector for bike and light
| Interface type | AC/DC | Type of connector usage: | Date Connector |
|---|---|---|---|
| Pin: | 2 3 4 pin | Appearance color | black, white, transparent, etc |
| Type: | M6 Mini waterproof connector | Voltage Rating: | 60-110 V |
Description of M6 Mini waterproof connector
Waterproof M6 Mini waterproof connector is a good choice for your application, it can be used data transfer application and sensor application etc.
| Operation Parameters | |
| Voltage Rating | 110VAC max |
| Current Rating | 6A max |
| Min Wire Size OD | 3.5mm |
| Max Wire Size OD | 6mm |
| Max.Cable Cross Section Area | 0.2mm2 ~ 0.5mm2 |
Features:
- Rated current: 6A.
- 2-5PIN power supply
- IP65 rating
- Voltage rating: 110V
- Cable Range: 3-6 mm
- UL, CCC, CE, RoHS approved
Main characteristics
- Sealed against dust and fluid (IP65)
- Vibration resistance,impact resistance,stretching resistance
- socket with cover
- Cable assembly support
- Customized pins quantity, cable size and length
FAQ
1. Q: What type waterproof connector do you have?
A: We have 17 series type waterproof connector,and make more than 3000types waterproof connector cable. Most of our connector is customized. We foucs on LED Waterproof connector,Assembly waterproof connector,Over-mold waterproof connector,T waterproof connector,Y customized waterproof connector.
2. Q:Is the sample avaliable and free?
A: sample is available, but it should be paid in advance. The cost of sample will be refunded after further order.
3. Q: Can you assured the quality?
A: Yes, we’ve gained the CE, RoHS, UL certification. And we’ve have strict QC team, all products will be tested before delivery.
4. Q: What’s the terms of payment?
A: We can accept T/T, LC, Paypal and Western Union
5. Q: What’s the delivery time?
A: It depends on the quantity, as usual it will takes 3-5 for small quantity.
