Diamond Tubing Broach Gauge Cutter Wireline Nickel Alloy
Diamond Tubing Broach Gauge Cutter Wireline
Ⅰ. Introduction
Diamond Tubing Broach Gauge Cutter Wireline are used to remove or broach tight spots
in tubing strings using hardened cutting teeth to cut or shear materials from the tubing wall.Pineapple broach Gauge Cutter Wireline can be manufactured in mll.any configurations and sizes to meet specific wellbore conditions.
Pineapple broach Gauge Cutter Wireline use diamond shaped teeth to remove scale, debris, or deformations from the inside of the tubing string.
Pineapple broaches can be disassembled and have the cutting sleeves changed should the teeth become damaged during operation.
Pineapple broaches can be used to repair tight collars, or deformations on the inside of the tubing string in preparation for equipment such as plunger lift systems, or logging operations.
Ⅱ. Specification
| O.D | F.N | Connection | PN. |
| 1.25＂-1.5＂-1.5＂ | 1.187＂ | 15/16-10UN | W21-05.**.00 |
| 1.5＂-2＂ | 1.375＂ | 15/16-10UN | W21-05.**.00 |
| 2＂-2.5＂ | 1.375＂ | 15/16-10UN | W21-05.**.00 |
| 2.5＂-3＂ | 1.75＂ | 1-1/16-10UN | W21-05.**.00 |
| 3＂-4＂ | 1.75＂ | 1-1/16-10UN | W21-05.**.00 |
| 4＂-5＂ | 2.313＂ | 1-9/16-10UN | W21-05.**.00 |
*Tools Can Be Manufactured To Any Size Required.
