Full-Color 80-330mm Wide Inkjet Digital Label Printing Machine
Key Benefits
-Highly flexible feeding system,suitable for all materials for 80-330mm wide label printing
-Imported high-precision industrial print head has higher fire ignition frequency and service life.
-The patch tracking electronic eye achieves accurate secondary surprint, comprehensively solves the problem of printing registration.
-Broad color gamut UV ink, vivid colors, with the Agfa color management system, can accurately restore the Pantone database colors.
-Resolution up to 600 X 1200 dpi.
-The fully integrated AGFA Apogee prepress workflow system ensures the highest level of reliability.
-Automatic winding and unwinding system can effectively prevent the substrate from shifting, ensure the orderliness of the winding and unwinding system and achieve non-stop production for a long time.
-Each print head has its own board to control, makes printhead printing more efficiency and easier to maintain.
-LED cold light curing unit, energy saving and high efficiency.
Specification
| Model | Label Smart 216S | Label Smart 330S |
| Techical Specification | ||
| Printing Technology | Piezoelectric Inkjet | |
| Print Method |
Roll to Roll,One -Side |
|
| Color Configuration | CMYK/W+CMYK/W+W+CMYK | |
| Number Of Channels | 6 | |
| Maximum Speed | 50m/min(600dpix600dpi);25m/min(600dpi×1200dpi) | |
| Resolutior | 600×600 dpi/600×1200 dp | |
| Ink Type | UV Ink | |
| Curing Method | UV LED | |
| Media | ||
| Media Width | 80-330 mm | |
| Maximum Print Width | 216 mm | 324mm |
| Media Thickness | 50-400 μm | |
| Media Type | PET,BOPP,PE,BOPA PP,Coated paper,Synthetic paper,Art paper,etc | |
| Maximum Media Roll Diameter | 600 mm | |
| Power | ||
| Power Supply | 380V | |
| Power | 15 kW | 30 kw |
| Compressed air | >6.5MPa | |
| Air consumption | >10L/min | |
| Environment | ||
| 0peration Temperature | 20-27°ºC | |
| Operation Humidity | 40-70%RH | |
| System Components | ||
| Skew Adjustment System | √ | |
| Electrostatic Dust Removal | √ | |
| Water Cooling System |
√ |
|
Label Samples
