40*5.57*2.12mm H-K9L Rhomic Prism Stereomicroscope KTP Crystals
Price:
USD281/piece
MOQ:
10 pieces
Delivery Time:
7 days
Brand:
WEIMENG
Product Description
40*5.57*2.12mm H-K9L Rhomic prism Stereomicroscope KTP Crystals
Products description:
Rhomic prism could make the beam horizontal displacemnet, which is widely used in optical instruments and optical devices.
The distance of beam translation can be determined by the size of the prism.
| Name | Rhombic prism |
| Application | optical instruments and optical devices |
| Description | make the beam horizontal displacement |
| Dimensional tolerance | ±0.1 mm |
| Angle tolerance | ±3′ |
| Parallelism | ≤10″ |
| Effective aperture | 85% |
| Chamfer | 45° |
| Coating | AR |
| Incidence angle | 45 degree |
| Material | H-K9L |
Products advantages:
1.Excellent material
2.Fine grinding
3.Factory supply
4.Professional enquipment
Application:
Stereomicroscope and periscope
