SPD is used to protect all kinds of electrical equipment in the power system from lightning over-voltage, operation over-voltage, power frequency transient over-voltage impact damage to an electrical appliance
The electrical circuit or communication lines because of outside interference peak current or voltage suddenly, the surge protector can in a very short time conducting shunt, so as to avoid damage to other equipment surge in the loop Installed front of inverter input and back of inverter output Installed in Parallel the spd is installed in the electric circuit with parallel, the first to play a protective role, the response time in the 25 to 50 nanosecond
DC 1000V 3P 20ka SPD Solar PV TUV CE DC Surge Protector
Price:
$14.50 - $20.00/ Piece
MOQ:
30 Piece/Pieces
Delivery Time:
Negotiable
Brand:
Suntree/OEM
Product Description
Suntree DC 1000V 3P 20-40ka SPD Solar PV Surge Protector Device with TUV CE Certificate
Product Description
![]()
1. DC Surge Protector Solar, protect against lightning surge voltage in solar system (photovoltaic power supply system).
2. These units must be installed in parallel on the DC networks to be protected and provide common and different modes protection. Its installed location are recommended at both ends of the DC power supply line (soalr panel side and inverter/converter side), ely if the line routing is external and long.
3. High energy MOVs equipped with specificthermal disconnectors and related failure indicators.
Product Parameters
|
SUP2-PV series surge protector
|
SUP2-PV
|
|
|
||
|
Normal PV system voltage
|
1000V
|
1200V
|
1500V
|
||
|
MCOV
|
1170V DC
|
1200V DC
|
1500V DC
|
||
|
Max system discharge current
|
40ka
|
30ka
|
30ka
|
||
|
Voltage protection level
|
≤4kv
|
≤4.5kv
|
≤4.5kv
|
||
|
Voltage protection level at 5ka
|
≤3.5kv
|
≤4kv
|
≤4kv
|
||
|
Integrated Fuse breaking capacity
/interrupting rating |
30ka/100v dc
|
30ka/1200v dc
|
30ka/1500v dc
|
||
|
Technology
|
Short-current interription overload protection
|
|
|
||
|
Operating temperature range
|
-40℃ + 80℃
|
|
|
||
|
Normal discharge current
|
12.5ka
|
|
|
||
|
Response time
|
<25ns
|
|
|
||
|
Operating state/fault indication
|
green(good) Red(replace)
|
|
|
||
|
Conductor rating and cross-sectionalarea
|
Min: 60/75℃ 1.5mm2 /14AWG Solid/ Flexible
|
|
|
||
|
|
Max: 60/75℃ 35mm2 /2AWG Standards /25mm2/
|
|
|
||
|
Mounting
|
35mm din rail per EN 60175
|
|
|
||
|
Enclosure material
|
UL 94V0 thermoplactic
|
|
|
||
|
Degree of protection
|
IP20
|
|
|
||
|
Capacity
|
3 Modules, din 43880
|
|
|
||
|
Standards information
|
IEC 61643-11 Type2, IEC 61643-1 Class Ⅱ
|
|
|
||
|
Product warranty
|
Five years
|
|
|
||
Application
Installation
Recommend Products
Company Information
XinChi Electric Group Co., Ltd is a group company,There are four branch companies subordinate to it. Registered trademark is "suntree".
Main Products: AC&DC Circuit breaker, Solar system parts,SISO-40 Solar Inverter/Cable
,Connector,Contactors, MCCB, ATS auto transfer switch, DC Combiner Box, Waterproof distribution box,etc.
Quality &Standards:Products are producted per ISO9001:2008, IEC60947, IEC60898,CB, SAA, TUV,CE,SONCAP,ROHS, Nemko, PCT,CCC etc
Main markets:Australia,New Zealand,&other worldwide markets
FAQ
Q: How can i trust you and your company ?
A: Suntree is a group company, we have 6 subcompanies. Have cooperation with LS, EKF the world-class companies. Our company over 500 employees, products pass CE,IEC,TUV,SAA, RCM, ROHS certificates.
Q:How long is your products warranty ?
A: The warranty period of our products is 2 Years.
Q:How about inspection?
A: We have the whole inspection system from raw material to end products include Transient test, delay test,mechanical life test and so on.
Q:What is the service offered by company?
A: We have the professional enginer team which can design and develop the mold to arrive different customer requirement.
We also have the sales team to offer good service from pre-sale to after-sale.
