Fourdrinier High Speed Toilet Paper Machine 1575 - 3500mm Model 13 - 23gsm
Production Description
Toilet and Tissue Paper Machine is a production line that use waste books paper,
wood pulp board, waste paper box, old corrugated carton, wheat straw pulp, wood
etc. to produce toilet paper, tissue paper,napkin paper daily paper ,etc.
Our toilet paper machine has many advantages: advanced technology, incredible quality,
high productivity, long service life, etc.
Technical Parameters
| Output paper | top quality toilet paper,tissue paper |
| Raw materia | virgin pulp,waste paper, deinking pulp, bamboo pulp, bagasse plup |
| Output weight | 13-23g/m2 |
| Capacity | 5-30 tons per day |
| Design speed | 150-300m/min |
| Net paper width | 1575mm-3500mm |
| Rail gauge | 2500-3000mm |
| Drive way | AC frequency converter and adjustable speed, processing transmission |
Flow Chart
Raw materials (waste paper)——pulper——vibrating sieve——pulp tank——pulp pump
——bleach machine(thruster)——refiner machine——pulp tank——pulp pump——pressure
sieve——pulp tank—— pulp pump——except sand machine——net box——cylinder——
blanket——paper making machine——drying——roll paper——the big finished jumbo paper
—— process machine
