3800mm Kraft Paper Making Machinery Rolled Recycled 400m / Min
3800mm Rolled Recycled Kraft Paper Making Machinery 400m / Min
Product Description
This machine can use different kinds of waste paper, recycled paper, virgin pulp, wheat straw, sugar canebagasse, cotton, wood as as material to make kraft paper, finished product can be jumbo paper roll.
Technical parameter
| Raw material | waster paper, recycled paper, agriculture waste |
| Output paper | craft paper, kraft paper, corrugated paper, flute paper, liner paper |
| Capacity | 200tons per day(24hours) |
| Net paper width | 1400mm(adjust according to clients' requirement) |
| Output paper weight | 100-220g/m² |
| Width of cylinder mould | 3800mm |
| Rail gauge | 2200mm |
| Wire width | 1600mm |
| Working speed | 300m/min |
| Design speed | 260m per min |
| Drive and control | Alternating current , frequency conversion, speed control, section drive |
Main Equipment
Pulp Making Equipments
High contentration hydrapulper, Vibrating screen, Pressure Screen,Double disc pulp refiner, Pulp pump, Low concertration cleaner,Impeller, High concentration cleaner, High speed washer, Decker thickener, Fiber separator, Rejector separator
Paper Making Equipments
Headbox, Cylinder mold, Cylinder vat, Touch roll, Press roll, Leading roll, Dryer, Sizing machine, Calender machine, Winding machine, Rewinder, Foundation frame
The structure and specifications of paper machine
Forming section→Press section→Dryer group section→Sizing press section→Calendering section →Paper scanner→ Reeling section→Rewinding section
What We Can Provide
1.Best configuration design of paper making machine according to your expected
paper product.
2.Guidance the installation, commissioning of the paper machine running and training.
3.Long-term after-sales service
Buying Guide
In order to recommend proper machine and make detailed technical proposal and exact offer for you as soon as possible,please help to confirm the following technical parameters?
1.What kind of paper do you want to produce?
Kraft paper,corrugated medium paper,gray paper board or test liner Craft paper?
2.What kind of raw material you will use?
(1) 100% waste carton paper (OCC)?
(2) waste craft paper+virgin pulp?
(3) wheat straw,bamboo,wood,bagasse,reed?
3.How many tons per day do you want to produce (in 24hours)?
4.Do you have requirement about paper width of jumbo roll?
5.What is the output paper gram weight (thickness)?
