26136rolls/ 8 Hours Paper Rewinding Machine
Main Features:
* Automatic paper cores loading and positioning, automatic kicking out finished logs, can use any size of paper cores;
* Automatic toilet roll tail trimming, gluing and sealing: 10-18mm long tails for easy pulling out;
* Advanced PLC control system;
* With LCD touch screen, parameters are set there, easy for operation;
* Machine alarms and stops when paper break or wrap up to ensure the high quality of the finished products;
* New technology to make high quality solid coreless toilet paper rolls, save more labor cost(optional);
* With high precision screwy perforating blades: 2~4 perforating blades to make clear perforation;
* Pneumatic back-stands: pneumatic jumbo roll loading, and pneumatic wide-belt paper unwinding, driving, and individual web tension controller for each jumbo roll;
* Speed controlled by inverter;
* Embossing pattern is customized (full embossing or edge embossing);
* Panel type frame structure achieves stable performance. (Strong structure & and high precision).
Main Parameters:
| Machine Model | 1092 | 1575 | 2000 | 2200 | 2500 | 2800 | 3000 |
| Parent Roll Width | 1300mm | 1800mm | 2000mm | 2200mm | 2500mm | 2800mm | 3000mm |
| Parent Roll Diameter | Φ 1200mm (other size can be customized) | ||||||
| Finished Roll Diameter | Φ 60~150mm (tightness adjustable) | ||||||
| Inner Core Diameter of Finished Roll | Φ20~50 mm | ||||||
| Inner Core Diameter of Parent Roll | Φ 3”/ 76.2 mm (other size can be customized) | ||||||
| Perforation Pitch | 4 perforating blades 90~160mm, 2 perforating blades 180~320mm(customized) | ||||||
| Speed | Design speed: 180~208 m/min; operation speed: 0~190m/min. | ||||||
| Parameter Setting | HMI (LCD screen operation panel) | ||||||
| Programming Controller | PLC (MITSUBISHI) | ||||||
| LCD Touch Screen | MITSUBISHI | ||||||
| Braking | Electronic and air pressure control | ||||||
| Pneumatic System | 3HP air compressor, mini. pressure 5kg/cm2Pa (prepared by users) | ||||||
| Finished Products Sheets Control | Increase gradually till reach the set diameter | ||||||
| Dimension(L×W×H) | 6200 x (1600~3600) x 2300mm(depends on the model and configuration) | ||||||
| Weight | Depends on the model and configuration | ||||||
| Unwinding Stands | 1~3 for 1~3 parent rolls (customized) | ||||||
| Options: | |||||||
| Embosser | Single embossing or double embossing | ||||||
| Edge Embosser | Steel to steel | ||||||
| Perforating Device | Pneumatic control | ||||||
| Remote Communications Server | Modem | ||||||
| Finished Roll Rewinding | With core or coreless rewinding system | ||||||
| Calendering Device | Steel to steel or steel to rubber roller | ||||||
* Toilet paper logs accumulator (optional)
* Toilet paper logs cutters (manual band saw cutter, automatic band saw cutter or automatic log saw)
* Single toilet roll packing machine (manual sealer or auto wrapper)
* Bundle packing machine (manual sealer or auto bundle packing machine)
