3 Inches Paper Rewinding Machine
Fully Automatic Toilet Paper Roll and Kitchen Towel Rewinding Machine
outline.
Automatic toilet paper rewinding machine is for toilet paper roll processing. Machine have core feeding unit, can do both with and without core. Raw material from jumbo roll after full embossing or edge embossing, then perforation, end cutting and spray the tail glue become a log. Then it can working with cutting machine and packing machine to become the finished products. The machine is controlled by PLC, people operate it through touch screen, the whole process is automatic, easy to operate, lower the man cost. And Our machine can special-made according to clients’ requirements.
Automatic core feeding system, automatic log pusher after rewinding, then rewind the new log again.
Automatic edge-trimming, core feeding, glue spraying and sealing synchronously in one time. Leaving 10-18mm tail, easy to rewind again, so reducing shortcut waste and save the cost.
Adopts international advanced PLC programmable controlling technique, man-machine interface operation, data set and parametric fault shows on touch screen.
Adopts 4 pieces high Precision spiral knives, low noise, clear perforation, adopt gearbox to have bigger range.
Three horizontal type back stands, pneumatic loading system, with wide driving flat belts; each jumbo roll can be adjusted independently.
Embossment Unit: adopt point to point embossing rollers, making the two layers match well, the paper is soft and has clear patterns
Adopt jogging switches for wearing the paper, easy and safe to operate.
services.
Our company provides a one-year warranty for the quality of the machines, and we can send the engineers to overseas for guidance.
Before purchasing the machine, you can come to our company in advance to check the machine, send special personnel to track and explain.
If you are new to this business. We will provide properly program from jumbo roll paper to finished products, to help you get familiar with this line and start business well.
We can special made machine according to client’s requirement.
We can recommend related raw material suppliers to you like jumbo roll, packing film if you like.
.We can help you to find shipping forwarder and get the documents you need for customs clearance to help you make it easy.
