1575mm 10T/D Kraft Liner Paper Making Machinery Carton Box 150m/Min
Products Description
Kraft and Corrugated Paper Making Machine is a production line that use waste books paper, wood
pulp board, waste paper box, old corrugated carton, wheat straw pulp, wood etc. to produce Kraft
paper,test liner paper, corrugated paper, fluting paper, cardboard paper.
Technical Specifications
| 1. Raw material: | Waste paper,wood pulp,carton paper |
| 2.Product Variety: | Kraft paper ,corrugated paper |
| 3.Paper width: | 1575mm |
| 4.Quantitative: | 80-300g/㎡ |
| 5.Design speed | 150m/min |
| 6.Working speed | 80-150m/min |
| 7.Rail gauge: | 2800mm |
| 8.Transmission way: | AC variable frequency,section drive |
| 9.Arrangement | Single floor layout |
| 10.Capacity: | 10T/D(24hours) |
Flow Chart
Raw materials (waste paper)--pulper--vibrating sieve--pulp tank--pulp pump--bleach
machine(thruster)--refiner machine-- pulp tank---pulp pump--pressure sieve--pulp
tank-- pulp pump--except sand machine--net box--cylinder--blanket--paper making
machine--drying--roll paper--the big finished jumbo paper -- process machine
Kraft and corrugated Paper Making Machine Is Mainly Used as The Package Material, High Strength,
Brown Color. Full Bleached or The Half Bleached Kraf Paper Pulp Is Light Brown Color , Cream Color,
or The White Color. Most Are Jumbo Rolls, Some Are Sheets. The Kraft Paper Is Generally Made Into
The Cement Paper Bags, Envolope, and Cables Protective Paper. Good Quality Waste Carton Recycle
Corrugated Paper Making Machine.
