300T/D Yarn Tube Paper Making Machine For Paper Mill 400m/Min
Kraft Paper Machine Instruction:
Paper machinery manufacturer kraft liner paper making machine is mainly used for making
cardboard and corrugated base paper.Paper machine is consist of headbox, wire section,
press section, front drying section, oblique surface sizing machine, back drying section,
calender section, reel section. Provide whole set pulping equipment included pulper, screening
equipment, remove slag equipment and approach system of paper machine.
Technical Specifications
| 1. Raw material: | Waste paper,wood pulp,carton paper |
| 2.Product Variety: | Kraft paper ,corrugated paper |
| 3.Paper width: | 3800mm |
| 4.Quantitative: | 80-300g/㎡ |
| 5.Design speed | 350m/min |
| 6.Working speed | 180-350m/min |
| 7.Rail gauge: | 4600mm |
| 8.Transmission way: | AC variable frequency,section drive |
| 9.Arrangement: | Fourdrininer |
| 10.Capacity: | 150T/D(24hours) |
| 11.Output paper humidity: | 4%~8% |
Our Services & Strength
(1) professional engineer team with 30 years experience;
(2) we can supply turn-key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualified product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: if any problem of machine, we will recall it and change a new one for free;
