SS304 4200mm 200T/D Kraft Paper Making Machinery Pneumatic Winding
High Quality 1092mm 10T Kraft Paper Machines
The paper machine is mainly divided into the following parts: Headbox, Fourdrinier Wire Section, Press Section, Front Dryer Section, Beveled Surface Sizing Machine, Back Dryer Section, Reeling Section.
Technical Data
|
Raw material |
Waster paper, recycled paper, agriculture waste |
|
Output paper |
Kraft paper, corrugated paper, flute paper, liner paper |
|
Capacity |
40tons per day(24hours) |
|
Net paper width |
2200mm; |
|
Output paper weight |
60-150g/m2 |
|
Width of cylinder mould |
2600mm |
|
Bearing center-center |
3100mm |
|
Bearing center-center |
42--179m per min |
|
Design speed |
180m per min |
|
Drive and control |
Alternating current , frequency conversion, speed control, section drive |
Flow Chart
Raw materials (waste paper)--pulper--vibrating sieve--pulp tank--pulp pump--bleach
machine(thruster)--refiner machine-- pulp tank---pulp pump--pressure sieve--pulp
tank-- pulp pump--except sand machine--net box--cylinder--blanket--paper making
machine--drying--roll paper--the big finished jumbo paper -- process machine
