Liquid Normal Gas LNG Cryogenic Fuel Tank Semi Trailer three axles
Liquid normal gas LNG cryogenic fuel tank semi trailer for sale
LNG semi trailer tank
LNG semi trailer tank is used for tranporting liquid normal gas (LNG-main component is CH4).
LNG is normal fuel gas. It have to be liquefied to be transported.
LNG has to meet the conditions of -161.5 degrees Celsius and 0.1 MPa. So it is important to
have good quality.
Genron Vehicle has been in the tank field for more than 20 years. We export oil tanks, LPG
tanks, LNG semi trailer, bulk tanks, asphalt tanks and so on all round the world. Welcome to
visit our factory and get video phone calls in any time.
| Tank Body | |
| Dimension | 13000×2500×3920mm ( Exact size depends on the final design) |
| Tare weight | About15500KGS |
| Loading Capacity | 23000KG / 52.6m3 (Water Capacity ,Dischargeable Capacity :47.3m3) |
| Tanker Body | 6mm (inside) 4mm (Outside) thickness |
| Material:S30408(RP1.0) Outside:Q345R | |
| End Plate | EHA2350×7(6),EHA2486×7(6) |
| Working Pressure | Max.0.65 MPa |
| Discharge Valve | 06Cr19Ni10 Seamless Steel Pipe |
| Chassis | |
| Fir extinguisher | TWO pieces |
| Axle | FUWA/ brand 13T / three axles |
| Landing Gear | JOST C200T |
| King Pin | JOST 2.00 inch bolt-in king pin |
| Suspension | Mechanical suspension special for LNG tanker |
| Leaf Spring | 10 PCS |
| Pneumatic Braking System | 6 relay valves; Spring brake chamber; one piece of 45L air tanks. |
| Rim | 9.00-22.5 China Brand 12 pcs Aluminum |
| Tire | /12.00R22.5 12 pcs |
| ABS | Optional |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| Accessories | One standard Aluminum tool box Aluminum Mud Guard |
| Shipping Terms | By Bulk Cargo ,RORO or 40HQ Containers |
LNG Semi trailer will be transported by bulk and good packed.
