L320 L175 L210 L245 GB / T3091 Carbon Steel ERW Pipe

L320 L175 L210 L245 GB / T3091 Carbon Steel ERW Pipe

GB / T3091 ERW Carbon Steel Pipe Use In Various Engineering Purposes, Fencing, Scaffolding Etc

Electric Resistance Welded pipe is used for welding pipe. Straight seam high frequency welded pipe has the characteristics of relatively simple process and rapid continuous production. It is widely used in civil construction, petrochemical industry, light industry and other departments.Used for making various engineering components and light industrial products.

Electric Resistance Welded  is based on the principle of electromagnetic induction and the skin effect, proximity effect and eddy current thermal effect of ac charge in the conductor, so that the steel at the edge of the weld is partially heated to the melting state, and then the butt weld is extruded by the roller to achieve crystal indirect fusion, so as to achieve the purpose of weld welding.High-frequency welding is a kind of induction welding (or pressure contact welding), it does not need weld filler, no welding spatter, welding heat affected zone is narrow, beautiful welding molding, good welding mechanical properties, and other advantages, so it has been widely used in the production of steel pipe.

The Round Carbon ERW Steel Pipe adopts the carbon steel with high strength which is available to meet the ERM specification to make sure that it can work steadily and consistently.

Designed with the resistance to corruption, water, oxygen and dust, it is convenient to maintain and clean, which is available to maintain original after the long-term use. And it is endurable with prolonged life circle that it can be used for a long time.

Standard:API 5L, ASTM A500, ASTM A252, ASTM 53, EN10217, DIN 2458, IS 3589, JIS G3452, BS1387

ERW :Electric Resistance Welded pipe

Steel Grade:API 5L PSL1 & PSL2: GR B, X42, X46, X56, X60, X65, X70
ASTM A53: GR.A, GR.B
EN10210/EN10219: S275, S275JR, S355JRH, S355J2H
GB/T3091: Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555

Out Diameter:114.3mm - 812.8mm (4"-32")

​Length:3M-18M

Wall Thk:4mm-22mm

Usage:Used for construction field, low pressure liquid transportation, in various engineering purposes, fencing, scaffolding etc.

Certificate:ISO 9001, ISO 14001, OHSAS 18001, API 5L PSL1&PSL2, CE (CPR & PED), GOST Certificates

Surface:Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating, Bitumen Coating, Black Oil coating as per customer’s requirement

Tests:Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test.

MTC:EN 10204/3.1B, EN 10204/3.2 (with Third Party Inspection

Size & Thickness:
