X65 Saw Steel Pipe

A wide range of the finished product specifications, weld toughness, ductility, uniformity and dense, with a large diameter, wall thickness, high pressure resistance, low-temperature corrosion resistance, etc.. Required steel pipe in the construction of high-strength, high toughness, high-quality long-distance oil and gas pipelines, mostly large diameter thick wall LSAW.
Longitudinally welded steel pipes are used in onshore and offshore oil and gas pipelines requiring critical service, high performance and tight tolerances. LSAW pipes are also used in conveyance of flammable & nonflammable liquids, and as structural members in construction projects.

LSAW pipe (longitudinal Submerged Arc Welding Pipe) is fromed by JCOE with one straight welded seam, the outer diameters usually from 406.4mm to 1422mm. When the outer diameter is 914.4mm above, it’s allowed two straight welded seams. LSAW pipe is used to convey low pressure liquid meida or high pressure petroleum or natural gas, and can be also used widely in structural supports or foundation. The advantage for LSAW type is they could produce more thick wall thickness of pipes, maximum to 120mm.
Size:
Outer Diameter:406.4mm-1422mm
Wall Thickness: 9.53mm-50mm
Length: 6mtr-12.5mtr
End:square ends (straight cut, saw cut, and torch cut). or beveled for welding, beveled,
Surface: Lightly oiled, Hot dip galvanized, Electro galvanized, Black, Bare, Varnish coating/Anti rust oil, Protective Coatings
Packing:Plastic plugs in both ends, Hexagonal bundles of max. 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips, Plastic caps.
Test:Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield
strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test.
