Oil Filed API 5L X52 S235 Electric Resistance Welded Tubes
Oil Filed API 5L X52 S235 Electric Resistance Welded Tubes
ERW (Electric Resistance Welded), HFI (High Frequency Induction), HFW (High-Frequency Welding)
ERW Black Steel Pipes and tubes are used in various engineering purposes, oil And gas transportation, line pipes etc. These tubes & pipes are available in varying qualities, wall thickness, diameters and finishes depending on the requirement of the end-users.
In manufacturing these ERW pipes & tubes, we utilize superior quality, continuous casted , fully killed, fin-grain, control-rolled, low carbon steel. High strength corrosion resistance, high malleability, superior strength, sturdy & durability are the special features of high performance ERW steel pipes & tubes that are manufactured by us.
Being a quality conscious manufacturer & exporter, our ERW steel pipes and tubes are processed through numerous tests including a hydro-test, an ultrasonic weld inspection, bevel check, micrometer check, straightness evaluation, and ring gouge to ensure it's quality.
Quality Standards:
API 5L Line Pipe for oil and gas
Payment Term: T/T, L/C at sight or negotiate
Delivery time: 7 day at fastest, based on total quantity or as customers’ requirements
Packing: Plastic plugs in both ends, Hexagonal bundles of max. 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips, Plastic caps.
Supply ability: 50,000 Metric Tons/Month
Loading port: Tianjin(Xingang) Port
| Specification | OD | 114.3mm-610mm (4"-24") |
| WT | 3.5mm-22mm | |
| Length | 3mtr-18mtr | |
| Surface |
Lightly oiled, Hot dip galvanized, Electro galvanized, Black painted, Varnish coating/Anti rust oil, Protective Coatings (Coal Tar Epoxy, Fusion Bond Epoxy, 3-layers PE)
|
|
| End | Plain/square ends (straight cut, saw cut, and torch cut), or Beveled ends, or Threaded ends, or Grooved ends. | |
| Steel grades |
BS 1387: Class A, Class B, Class C EN10210/EN10219: S235, S235JR, S235J2H, S275, S275JR, S355JRH, S355J2H API 5L: GR.A, GR.B, X42, X46, X52, X56, X60, X65 X70 ASTM A252: GR.1, GR.2, GR.3 ASTM A500: GR.A, GR.B, GR.C, GR.D
|
|
| Coating Standard |
ISO 21809: Petroleum and natural gas industries -- External coatings for buried or submerged pipelines used in pipeline transportation systems AWWA C210: Liquid-Epoxy Coatings and Linings for Steel Water Pipe and Fittings
|
|
