Anti static High Precision Alumina Ceramic Roller
Alumina Ceramic Rod for Electric Appliance, 95% Alumina Porcelain Pole for Electric Heater, Thermostat and Insulator
1. Description:
The ceramic rod series are made of 95% alumina material. The production methods include dry pressing and hot press injection.
2. Key Words:
Ceramic rod, Ceramic pin, Thermostat, Precision ceramic part, ceramic roller, Electric and Electronics,High temperature resistance, outstanding insulation,Anti corrosion, abrasion resistance, impact resistance,High precision, high stability, wide range of measurement,95% alumina,hot injection process, glazed,white, beige, pink or customized,temperature control system, electrics and electronics, precision manufacture.
3. Parameters:
| Product Parameters | ||
| Physical Property | Material | 95% Alumina |
| Production Process | Hot Injection Pressing+Glazing | |
| Product Dimension | Per customers' drawing | |
| Density (g/cm3) | 3.70-3.75g/cm3 | |
| Water Absorption | 0% | |
| Mechanical Performance | Flexural Strength (Mpa) | 310Mpa |
| Modulus of Elasticity (Gpa) | 310Gpa | |
| Hardness (Gpa) | 12.9Gpa | |
| Poisson Ratio | 0.23 | |
| Thermal Character | Linear Thermal Expansion Coefficient | 7.2 |
| Heat Conductivity (W/mk) | 23 | |
| Electrical Property | Dielectric Constant | 9.2 |
| Dielectric Loss Tangent (x10-4) | 8 | |
| Insulation Strength (x106V/M) | 15 | |
