Customized Boiler Spares Water Heating Fishor EPDM/NBR/Hepdm/HNBR Plate Heat Exchanger
Price:
10000USD
MOQ:
1
Delivery Time:
8-10 days
Brand:
DGXT
Product Description
DGXT plate heat Exchanger
Heat Exchanger Plate gaskets Material Choose reference:
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
Application: Heating and Cooling for liquid.
a. Refrigeration: used as condenser and evaporator.
b. HVAC: Intermediate heat exchangers for boilers, intermediate heat exchangers for high-rise buildings, etc.
c. Chemical industry: Soda ash industry, synthetic ammonia, alcohol fermentation, resin synthesis cooling, etc.
d. Metallurgical industry: heating or cooling of aluminate mother liquor, cooling of steel making process, etc.
e. Machinery industry: various quenching liquid cooling, reducer lubricating oil cooling, etc.
f. Power industry: high-voltage transformer oil cooling, generator bearing oil cooling, etc.
g. Paper industry: heat recovery from bleaching process, heating washing slurry, etc.
h. Textile industry: cooling of viscose silk alkali aqueous solution, boiling nitrocellulose cooling, etc.
i. Food industry: fruit juice mie bacteria cooling, animal and vegetable oil heating and cooling.
j. Grease technology: soap-based drying under normal pressure, heating or cooling of various process liquids.
k. Central heating: heating in waste heat area of thermal power plant, heating bath water.
l. Others: petroleum, medicine, ships, seawater desalination, geothermal utilization.
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
![Boiler Spares Water Heating Fishor Plate Heat Exchanger]()
Heat Exchanger Plate Material Choose reference:
| Plate matrial | Adapt Liquid |
| Stainless steel(304,316) | Pure water,stem water,Edible oil,mineral oil |
| (Ti,Ti-Pa) | Sea water,Salt water,Salt compounds |
| 20Cr,18Ni,6Mo(2455Mo) | Dilute sulfuric acid, dilute sulfate, organic water solution |
| (Ni) | High Temperature and High Concentration Caustic Sodium |
| HASTELLOY(C276,D25,B2G) | Concentrated sulfuric acid, hydrochloric acid and phosphoric acid |
Heat Exchanger Plate gaskets Material Choose reference:
| Sealing material: | adapt temperature | Suitable for fluid |
| NBR | -15~+120ºC | Water, sea water, cooking oil, salt water |
| HNBR | -15~+140ºC | High temperature mineral oil, high temperature water |
| EPDM | -25~+170ºC | Hot water, water vapor, acid, alkali |
| Viton | -5~+130ºC | Acid, alkali, fluid |
We Supply all kinds of heat exchanger replacement plate and gaskets service,completed machine service.
including Gea, Apv, Funke, Hisaka, Muller, Sondex, Thermowave, etc
FS Series
| Model | DN | Flow Rate Max | P.NO MAX | Max surface |
| mm | M2 | pcs | M2 | |
| FS40 | 32 | 20 | 50 | 3 |
| FS70 | 50 | 40 | 76 | 5 |
| FS140 | 50 | 40 | 427 | 59 |
| FS170 | 50/65 | 40 | 609 | 100 |
| FS190 | 65 | 65 | 609 | 115 |
| FS220A | 100 | 180 | 698 | 146 |
| FS220B | 100 | 165 | 538 | 118 |
| FS420A | 150 | 380 | 670 | 274 |
| FS420B | 150 | 360 | 532 | 223 |
| FS620 | 150 | 380 | 670 | 415 |
| FS430 | 200 | 700 | 695 | 300 |
| FS650 | 200 | 700 | 695 | 450 |
| FS1000 | 200 | 700 | 695 | 695 |
| FS1300 | 200 | 700 | 695 | 900 |
| FS800A | 300 | 1600 | 930 | 744 |
| FS800B | 300 | 1600 | 930 | 750 |
| FS1200 | 300 | 1600 | 930 | 1115 |
| FS1900 | 300/500 | 1600 | 930/930 | 1750/2210 |
| FS2500 | 300 | 1600 | 930 | 2334 |
| FS3000 | 500 | 4000+ | 930 | 1860 |
Application: Heating and Cooling for liquid.
a. Refrigeration: used as condenser and evaporator.
b. HVAC: Intermediate heat exchangers for boilers, intermediate heat exchangers for high-rise buildings, etc.
c. Chemical industry: Soda ash industry, synthetic ammonia, alcohol fermentation, resin synthesis cooling, etc.
d. Metallurgical industry: heating or cooling of aluminate mother liquor, cooling of steel making process, etc.
e. Machinery industry: various quenching liquid cooling, reducer lubricating oil cooling, etc.
f. Power industry: high-voltage transformer oil cooling, generator bearing oil cooling, etc.
g. Paper industry: heat recovery from bleaching process, heating washing slurry, etc.
h. Textile industry: cooling of viscose silk alkali aqueous solution, boiling nitrocellulose cooling, etc.
i. Food industry: fruit juice mie bacteria cooling, animal and vegetable oil heating and cooling.
j. Grease technology: soap-based drying under normal pressure, heating or cooling of various process liquids.
k. Central heating: heating in waste heat area of thermal power plant, heating bath water.
l. Others: petroleum, medicine, ships, seawater desalination, geothermal utilization.
