10 Meters Industrial IP68 10V Submersible Pressure Transducer
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
5-10days
Brand:
OEM
Product Description
10 Meters Industrial IP68 10V Submersible Pressure Transducer
Product Descriptio
ip68 submersible pressure transmitter 0 10v immersible level sensor for water depth measuring
Submersible level transmitter , based on the principle that, the hydro static pressure of measured level is proportional to the height of this liquid , adopts the piezoresistive effect of diffused silicon , converts pressure into electrical signal, by temperature compensation and linear calibration , then converts into standard current , voltage and RS485 signals and outputs .
It can be directly connected with PLC/DCS ,display instrument and computer , remote signal transmission also can be carried out. The level transmitter is widely used in liquids measurement of petrochemical , water supply and drainage , environmental protection and electric power .
The intemal ASIC converts the sensor millivolt signal into standard voltage, curent or frequency signal, which can be directly connected with computer interface card, control instrument, intelligent instrument or PLC.
It is widely used in process control, av iation, aerospace, automotive, medical equipment, HV AC and other fields.
|
Medium
|
Liquid
|
Measuring range
|
10 meters
|
|
Output
|
4-20mA or 0-5V;0-10V;RS485
|
Power supply
|
18-36VDC
|
|
Accuracy
|
0.25%F.S
|
Temperature
|
-20~80C
|
|
Protection class
|
IP68
|
Sealing material
|
Nitrile rubber
|
|
Probe material
|
stainless steel 304
|
Keywords
|
submersible pressure transmitter
|
Feature:
- High quality amplifier chip
- Industrial class 1500VDC withstand voltage
- It can be used in a variety of industrial control occasions
- Oblong integrated circuit board chip is adopted to accelerate heat dissipation of circuit board and improve product stability.
- 304/316 stainless steel meterial, seals construction with o-ringe,8 holes filter cap waterproof IP68
