PLC Control 2500mm Rebar Welding Machine Water Cooling
Plc Control Rebar Roll Welded Reinforcing Mesh Welding Machine
In addition to parameter setting, Plc Control Rebar Roll Welded Reinforcing Mesh Welding Machine is also used to display the whole machine failure and safety status, so that the system is safe and reliable, easy to run and maintain, easy to operate and intuitive. Plc Control Rebar Roll Welded Reinforcing Mesh Welding Machine simplicity of operator and easy to learn, it takes only one person to complete the operation. Plc Control Rebar Roll Welded Reinforcing Mesh Welding Machine can optional mesh stacking device, mesh bending device and mesh rolling device and so on. It can save labors when use the Plc Control Rebar Roll Welded Reinforcing Mesh Welding Machine.
Plc Control Rebar Roll Welded Reinforcing Mesh Welding Machine is designed as detachable structure for easy adjustment and maintenance. Transformer, upper and lower electrodes using forced water cooling, and equipped with flow protection device, Plc Control Rebar Roll Welded Reinforcing Mesh Welding Machine can work reliably continuously. The unit of Plc Control Rebar Roll Welded Reinforcing Mesh Welding Machine is designed as detachable structure for easy adjustment and maintenance. Transformer, upper and lower electrodes using forced water cooling, and equipped with flow protection device, Plc Control Rebar Roll Welded Reinforcing Mesh Welding Machine can work reliably continuously.
| No. | Name | Brand | Note |
| 1 | Servo motor and driver | DELTA | |
| 2 | Pneumatic component | STNC/ISAIAH | |
| 3 | Linear guideway | PMI | |
| 4 | PLC | DELTA | |
| 5 | Touch screen | DELTA | |
| 6 | Welding electrode | Chromium zirconium bronze | |
| 7 | Switch and button | SCHNEIDER | |
| 8 | Sensor | RUNAN | |
| 9 | Microcomputer controller | FANGZHENG | |
| 10 | Transformer | FANGZHENG | |
| 11 | Chain and cable | ECHU |
1) Cross wires are pre-cut. The pre-cut wires are sent into the wire plucking section from storage area under the drive of motor. After inspection, wire catching plate can send wires (one piece once Time) on the position between electrodes to weld. After finishing one row of welding, the longitudinal wires step one grid and one piece of cross wire drops at the same time and then welding starts. After some times welding like this, one mesh will be finished.
2) This device is equipped with an inspecting device. If none of cross wires drops, the device will alarm automatically. After adjusting by worker, the machine will continue producing, which greatly decrease the damage of equipment and meshes.
3) Materials area is equipped the positioning device to store the wires with different lengths.
