DWDM System LC/APC Female To Male 15dB Fiber Optic Attenuator
WDM And DWDM System 15dB LC/APC Female to Male Fiber Optic Attenuator Kits
Product Description:
As optical passive devices, Geehe's Optic Pad attenuators are mainly used in fiber optic to debug optical power performance & optical instrument calibration correction & fiber signal attenuation to ensure the optical power in a stable and desired level in the link without any changes on its original transmission wave.
Depending on the project or need, fixed attenuators can limit, or attenuate, the amount of light passing through to the exact level your project or application requires.
LC /APC Attenuator Features And Benefits:
- Precise attenuation values
- Low PDL & insertion loss
- Precisional reflection polishing
- High power 1W continuous operation tested over 1000 hours
- Low ripple broadband design for operation at both 1310 and 1550 nm
- Fully compatible and highly reliable, highly reliable physical contact connectors
- 100% Factory tested
- Multimode attenuators available
Specification& Parameters:
| Parameter | Value | |||||
| Physical Characteristics | Plastic Material | UL 94V-0ABS high-impact thermoplastic | ||||
| Fiber Material | Metal-ion doped optical fiber | |||||
| Mechanical Characteristics | Operating Temperature(℃) | -40 ~ +85 | ||||
| Storage Temperature(℃) | -40 ~ +85 | |||||
| Optical Performance | Operating Bandwidth | 1250nm~1625nm | ||||
| Center Wavelength | 1310nm and 1550nm | |||||
| Attenuation Tolerance | 1 to 10 dB:±0.5dB 11 to 30 dB:±0.5%dB |
|||||
| Return Loss UPC (dB) | ≥45 | |||||
| Return Loss APC(dB) | ≥55 | |||||
| PDL | ≤0.1 | |||||
| Packaging | Clear Ziploc Bag,1 Unit Per Bag | |||||
Ordering Information:
| OTA- | HF- | XX- | X- | A- | XX- | |
| HF: Hight return loss type | LC: LC SC: SC FC: FC |
1: APC 2:UPC |
03: 03DB 04: 04DB |
|||
| Attenuator Type | Connector | Interface Polish | Attenuation Value | |||
LC APC Attenuator Application:
- DWDM
- Optical sensors
- Test & measurement
- Telecommunications
