Diamond Expanding Wire Mesh Metal Sheet Anodized 2m Width 6m Length
Price:
$2.15-$3.25/M2
MOQ:
200M2
Delivery Time:
according to the customer's qty
Brand:
Source Wire Mesh
Product Description
Gold Supplier air filters outer wire mesh expanded metal mesh
1) Material: Aluminum ,galvanized sheet, stainless steel wire mesh, copper mesh
2) Pattern: Opening in the shape of diamond, hexagonal or special shape.
3) Features: The expanded metal mesh is strong and durable, with pleasing appearance in its shapes.
4) Sizes: Long way of mesh: 3-100mm ;
Short way of mesh: 2-80mm;
Thickness: 0.3-5mm;
| EXPENDED FLATTENED MESH | |||||
| LWD(mm) | SWD(mm) | Strand Width | Strand Gauge | %Free Area | Approx.Kg/m2 |
| 6.05 | 3.38 | 0.5 | 0.8 | 50 | 2.1 |
| 10.24 | 5.84 | 0.5 | 0.8 | 75 | 1.2 |
| 10.24 | 5.84 | 0.9 | 1.2 | 65 | 3.2 |
| 3.80 | 2.10 | 0.8 | 0.6 | 46 | 2.1 |
| 14.20 | 4.80 | 1.8 | 0.9 | 52 | 3.3 |
| 24.40 | 7.10 | 2.4 | 1.1 | 57 | 3.4 |
| 23.20 | 5.80 | 3.2 | 1.5 | 43 | 6.3 |
| 32.70 | 10.90 | 3.2 | 1.5 | 59 | 4 |
| 33.50 | 12.40 | 2.3 | 1.1 | 71 | 2.5 |
| 42.90 | 14.20 | 4.6 | 2.7 | 58 | 8.6 |
| 39.10 | 18.30 | 4.7 | 2.7 | 60 | 7.6 |
| 43.20 | 17.08 | 3.2 | 1.5 | 69 | 3.2 |
| 69.80 | 37.10 | 5.5 | 2.1 | 75 | 3.9 |
Specification
