Hot Dipped Galvanized Razor Barbed Wire BTO 22 450mm Coil 0.8mm thickness
Coil diameter 450MM BTO-22 Hot Dipped Galvanized Razor Barbed Wire
Razor Barbed Wire Product Description:
Hot Dipped Galvanized Razor Barbed Wire:
Hot Dipped Galvanized Razor Barbed Wire also named concertina razor wire,razor fencing wire,razor blade wire or dannert wire.It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets.With sharp blades and strong core wire,razor wire has the features of secure fencing,easy installation,age resistance and other properties.
Hot Dipped Galvanized Razor Barbed Wire material:
1. blade:stainless steel plate by one-time punching moulding
2. wire:stainless steel wire
3. ss302 ss304 ss316 ss316l
4. as your required
Hot Dipped Galvanized Razor Barbed Wire features:
1. anti-solarization and durable
2. economical and practical
3. beautiful appearance
4. easily constructed
5. anti-corrosion
6. anti-ageing
7. long use life
8. save cost
Specification List:
|
Razor Wire Size Specifications
|
|||||
|
Peference Model
|
Thickness (mm)
|
Wire Diameter (mm)
|
Barb Length
(mm) |
Bard Width
(mm) |
Bard Spacing
(mm) |
|
BTO-12
|
0.5±0.05
|
2.5±0.1
|
12±1
|
15±1
|
26±1
|
|
BTO-15
|
0.5±0.05
|
2.5±0.1
|
18±1
|
15±1
|
33±1
|
|
BTO-22
|
0.5±0.05
|
2.5±0.1
|
02±1
|
15±1
|
34±1
|
|
BTO-28
|
0.5±0.05
|
2.5±0.1
|
28
|
15
|
45±1
|
|
CBT-30
|
0.5±0.05
|
2.5±0.1
|
30
|
18
|
45±1
|
|
CBT-60
|
0.6±0.05
|
2.5±0.1
|
60±2
|
32±1
|
100±1
|
|
CBT-65
|
0.6±0.05
|
2.5±0.1
|
65±2
|
21±1
|
100±1
|
|
Outside Diameter
|
No. of Loops
|
Standard Length per Coil
|
Razor Type
|
Notes
|
|
450mm
|
33
|
7M-8M
|
CBT-60, 65
|
Single Coil
|
|
500mm
|
56
|
12M-13M
|
CBT-60, 65
|
Single Coil
|
|
700mm
|
56
|
13M-14M
|
CBT-60, 65
|
Single Coil
|
|
960mm
|
56
|
14M-15M
|
CBT-60, 65
|
Single Coil
|
|
450mm
|
56
|
8M-9M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
500mm
|
56
|
9M-10M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
600mm
|
56
|
10M-11M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
600mm
|
56
|
8M-10M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
700mm
|
56
|
10M-12M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
800mm
|
56
|
11M-13M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
900mm
|
56
|
12M-14M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
960mm
|
56
|
13M-15M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
980mm
|
56
|
14M-16M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
Product Images:
Concertina Wire Type
Concertina Wire Use:
FAQ:
Q:Do you have quality guaranteed?
A:All our sculptures are covered by 15-year Quality Guarantee.
Q:Could you supply Door-to-Door Delivery?
A:Yes, we are very good at Door to Door Delivery, please inform me your detailed address, then I will quote you the freight cost to your home directly.
Q:How do we ship the goods?
A:We will quote you the ocean freight, if the goods is not large, it will be loaded by air freight or Express. No matter any ways of transportation, our forwarders will provide professional service to ensure the goods arrives at your place smoothly.
Q:How do we go to your factory for visiting?
A:Please inform me your flight time, we will pick you up at our nearby airport, then drive to our factory for visiting.
