Heavy Duty Multiple Fission Conductor Lifter for Simultaneous Multi Conductor Handling and Enhanced Worker Safety
Price:
Negotiable
MOQ:
1 PCS
Delivery Time:
3-7days
Brand:
Suntech
Product Description
| Item number | Model |
Rated Load (KN) |
Hook slot length (mm) |
Weight (kg) |
Note |
| 19112 | ST25-2 | 2x12 | 120 | 13 | Two |
| 19113 | ST50-2 | 2x15 | 160 | 25 |
Two |
| 19114 | ST80-2 | 2x40 | 250 | 40 | Two |
| 19108 | ST36-3 | 3x12 | 120 | 21 |
Three |
| 19109 | ST75-3 | 3x25 | 160 | 35 | Three |
| 19110 | ST120-3 | 3x40 | 250 | 60 | Three |
| 19115 | ST48-4 | 4x12 | 120 | 35 | Four |
| 19116 | ST100-4 | 4x25 | 160 | 60 | Four |
| 19117 | ST160-4 | 4x40 | 250 | 90 | Four |
| 19118A | ST150-6 | 6x25 | 160 | 70 | Sex |
| 19118B | ST240-6 | 6x40 | 250 | 110 | Sex |
| 19119A | ST200-8 | 8x25 | 160 | 120 | Eight |
| 19119B | ST320-8 | 5+6 | 250 | 160 | Eight |
-
Simultaneous Multi Conductor Handling: The primary advantage of this lifter is its ability to engage and lift all sub-conductors of a bundle (whether two, three, or four) in a single, coordinated operation. This eliminates the need to lift and position each conductor individually, saving a substantial amount of time and labor. It ensures that the bundle's geometry is preserved during the lifting process, which is crucial for subsequent installation steps. -
Enhanced Worker Safety: Manually handling heavy, often energized, conductors at significant heights is a high risk activity. The Multiple Fission Conductor Lifter dramatically improves safety by allowing crews to perform lifting operations from a secure position, minimizing direct physical contact with the conductors. This reduces the risk of musculoskeletal injuries, drops, and accidents associated with manual lifting and positioning. -
Superior Conductor Protection: The lifter is designed with features that protect the conductor's surface from scratches, abrasion, and crushing. The contact points or gripping jaws are engineered to apply secure yet non damaging pressure to the conductors. This careful handling preserves the integrity of the conductor strands and its protective coatings, preventing points of future corrosion or electrical weakness. -
Precise Positioning and Alignment: This tool provides exceptional control during the lifting process, enabling crews to precisely position the conductor bundle for attachment to suspension assemblies, spacers, or other tower hardware. The ability to make fine adjustments easily ensures perfect alignment, which is critical for the long term aerodynamic and electrical performance of the line. -
Robust and Durable Construction: Built from high strength aluminum alloys or steel, the lifter is designed to withstand the rigors of field use. Its components are engineered to handle the full weight of the conductor bundle without deformation, ensuring reliability and longevity even when used frequently in demanding conditions. -
Adaptable to Various Bundle Configurations: Many models of this lifter are versatile, with adjustable components that can accommodate different bundle diameters and geometric arrangements (e.g., horizontal, vertical, or triangular). This adaptability makes it a cost effective tool for contractors who work on a variety of transmission line projects with different specifications. -
Operational Efficiency and Time Savings: By streamlining the conductor handling process, the lifter significantly accelerates tasks such as transferring conductors from stringing blocks to permanent hardware, or during maintenance operations like replacing spacers or dampers. The time saved on these critical path activities directly translates to reduced project duration and lower labor costs. -
Ease of Use and Ergonomic Design: Despite its robust capabilities, the lifter is designed for practical use in the field. It features ergonomic handles and a balanced weight distribution, making it manageable for a small crew to operate. The engagement and release mechanisms are straightforward, requiring minimal effort to secure and free the conductor bundle. -
A Vital Tool for Modern Power Grids: As power lines continue to evolve towards higher capacities using bundle conductors, the Multiple Fission Conductor Lifter has become a standard and necessary tool for professional utility crews. It represents a commitment to safety, quality, and efficiency in the construction and upkeep of critical electrical infrastructure.
