Factory Made High Thermal Conducticivity Graphite Boat Carbon Block For Project

Thin graphite boat, including a boat body arranged on one side such as a dry-loaded rod slot W, a spacer block and a positioning pin with a certain taper. The two ends of the boat body parallel to the rod-carrying slot W are respectively provided with grooves and spacer blocks The lower end boss is matched with the groove, and the positioning pin passes through the positioning hole in the middle of the groove and the positioning hole in the middle of the lower end of the pad; the distance between the bottom of the rod-carrying groove W and the bottom of the boat body, and the distance between the top and the boat body The distance from the bottom surface, the distance from the top surface of the cushion block to the upper convex surface, and the distance from the top surface of the cushion block and the boat body to the bottom surface of the boat body are 2.0-8 mm, 3-16 mm, and 3.8 respectively. -12 mm, 6.8-28 mm; the groove spacing, groove bottom width, groove height, and included angle of the bar-carrying groove W are 2.6-12.4 mm, 0.2-3 mm, 1.2-9 mm, 50°-60°, respectively; The utility model not only increases the output of a single furnace of the sintering furnace, prolongs the actual service life of the boat, but also saves boat materials.
