Sunfar Inverter Stepper Motor 3 Axis Aluminium CNC Router
T Slot Table 24000rpm 3 Axis Aluminium CNC Router
1. Machine body design with high strength and double driving motors of Y axis, which have more reasonable design, fast processing speed, easy-operated maintenance and low fault rate.
2. Advanced CNC processing system has powerful functions and humanized operation, as well as can receive data through U disk or network.
3. Imported and high precise linear guide ways have features such as stable operation, high precision and steady support, which prolong service life of machines.
4. Z axis adopts imported ball screw with industrial level can positioning accurately and make processing effects more perfect.
5. Energy-saving vacuum absorption table function and dust collectors can protect the environment.
6. Software has good compatibility. The machine can be compatible with various CAD/CAM design & making software such as TYPE3, Artcam, JD, Artcut, UG, MasterCAM, PowerMill and so on.
| Working Area (X*Y) | 1300mm*2500mm*200mm |
| Table Type | T-slot table |
| X,Y,Z Traveling Positioning Accuracy | ±0.03/200mm |
| X,Y,Z Repositioning Accuracy | ±0.03mm |
| Spindle | 3kw Air/ water cooling spindle |
| Spindle Speed | 0-18000RPM/24000RPM |
| Guider | Taiwan Hiwin Square Rail |
| Transmission Type | XY gears pinion,Z axis with ø20mm ballscrews |
| Control System | NC-studio control system |
| Motor | Stepper motor |
| Inverter | Sunfar Inverter |
| Collets | 3.175mm/6mm/12.7mm |
| Software | Artcam |
| Command | G code*.u00*.mmg*.pl |
| Voltage | 3P 380v, 50/60 Hz |
| Packing Size | 3200X2200X1800mm |
| N.W. | 1100kg |
| Warranty | 24 months for machine with 24 hours on-line technical support |
|
Optional parts: |
1.Dust Collects 5.rotary axis 6.different working area 7.semi-auto lubrication system 8.different power spindle
|
