China 232-40-05110 2324005110 Steering Cylinder Seal Kit For Komatsu GD37-6H GD600R-1 for sale

232-40-05110 2324005110 Steering Cylinder Seal Kit For Komatsu GD37-6H GD600R-1

Name: 232-40-05110 2324005110 Steering Cylinder Seal Kit For Komatsu GD37-6H GD600R-1
Brand: GUANGZHOU SUNCAR SEALS CO.,LTD.

Price Negotiable

Price: Negotiable

MOQ: Accept trial order

Delivery Time: 3-5 days after payment received(public holiday excluded)

Brand: SUNCAR

Product Description

232-40-05110 2324005110 Steering Cylinder Seal Kit For Komatsu GD37-6H GD600R-1 GD605A-1 GD705R-1 GD705R-2

Name	232-40-05110 2324005110 Steering Cylinder Seal Kit
Type	Steering Cylinder seal kit
Pressure	0~60MPa
Temperature	-45℃ +200℃
Speed	15m/s
Medium	Hydraulic oil, fire retardant liquid, water and others
Features	Pressure & Oil Resistant
Material

Part Numbers of Cylinder Service Kits:

707-99-78630	707-98-11300	707-98-04710
707-99-77230	707-98-11330	566-63-41001
707-98-36100	878000500	566-63-11500
707-98-10820	878000379	707-98-26901
707-98-10940	878000499	56B-50-16103
707-98-11240	878000503	707-99-37370
707-98-03400	878000497	721-98-04190
707-98-03460	878000498	707-99-56550
707-98-03450	707-98-22810	707-99-53270
707-98-14460	707-98-13020	707-99-85310
707-98-11270	707-99-47080	206-63-K1721
707-98-13880	707-99-39680	206-63-K1610
707-98-56210	707-99-56630	206-63-K1911
707-99-67290	707-98-26721	707-99-68410
707-99-77120	707-99-37180	707-99-96020
707-98-77210	707-99-37740	79242373
21D-61-12201	707-99-39790	79242473
21D-61-15170	707-99-39770	79732573
226-61-11220	707-99-38760	79482573
21D-61-14140	707-99-46420	79989473
21D-61-13160	707-99-37780	79989873
707-99-35310	707-99-38470	76826173
707-99-41300	707-99-46480	79453873
707-99-43300	707-99-46440	78044673
707-99-35300	707-99-46430	79545673
707-99-27650	707-99-53310	79454173
707-99-36190	707-99-37190	79545773
707-99-56720	707-99-45170	707-01-01020
707-99-43280	707-99-36380	707-01-07560
707-99-27510	707-99-39760	707-99-75145
707-99-36290	707-99-25780	707-99-43505
707-99-46230	707-98-35330	707-99-84415
707-98-28610	707-99-45080	707-98-85315
707-99-89270	707-99-27460	707-99-72100

Parts on group :

Pos.	Part No	Qty	Parts name
25	232-40-05012	[1]	SERVICE KIT,STEERING GEAR CASE
25	232-40-05011	[1]	SERVICE KIT,STEERING GEAR CASE
25.	232-40-13140	[1]	GASKET
25.	232-40-13470	[1]	SHIM, 0.5MM
25.	232-40-13480	[2]	SHIM, 0.2MM
25.	232-40-13490	[1]	SHIM, 0.1MM
25.	232-40-13560	[1]	GASKET
25.	232-40-13580	[1]	GASKET
25.	07000-03022	[1]	O-RING OEM
26	232-40-05021	[1]	SERVICE KIT,STEERING GEAR COVER
27	232-40-05031	[1]	SERVICE KIT,BEARING COVER
27.	232-40-13340	[1]	SHIM, 0.5MM
27.	232-40-13350	[2]	SHIM, 0.2MM
27.	232-40-13360	[1]	SHIM, 0.1MM
27.	07010-00025	[1]	SEAL
28	232-40-05040	[1]	SERVICE KIT,ARM SUPPORT
28.	232-40-13640	[1]	GASKET
28.	232-40-91170	[1]	SHIM, 0.2MM
28.	232-40-91180	[1]	SHIM, 0.35MM
28.	232-40-91190	[1]	SHIM, 0.5MM
29	232-40-05060	[1]	SERVICE KIT,STEERING GEAR
29.	234-40-13760	[1]	SEAL
29.	234-40-13710	[1]	SHIM
29.	234-40-13720	[1]	PACKING
29.	234-40-13580	[1]	SHIM
29.	234-40-13590	[1]	PACKING
29.	232-40-33180	[1]	SHIM
29.	232-40-33190	[1]	SHIM
29.	232-40-33230	[1]	SEAL
29	232-40-05070	[1]	SHIM AS'Y
29.	232-40-33520	[1]	SEAL
29.	232-40-33490	[1]	GASKET
29.	07000-12020	[1]	O-RING
29	232-40-05100	[1]	SERVICE KIT
29.	232-40-53130	[1]	SEAL
29.	232-40-53280	[1]	SEAL
29.	07000-02075	[1]	O-RING
29.	232-40-53370	[1]	O-RING
29.	232-40-53410	[2]	PACKING
29.	232-40-53440	[1]	O-RING
30	232-41-05031	[1]	SERVICE KIT,STEERING CYLINDER (OP)
30.	232-41-25220	[1]	O-RING (OP)
30.	232-41-25250	[3]	V-PACKING (OP)
30.	232-41-25260	[1]	SEAL (OP)
30.	232-41-25340	[2]	O-RING (OP)
30.	232-41-25370	[1]	O-RING (OP)
30.	232-41-25410	[2]	O-RING (OP)
30.	232-41-25420	[2]	RING (OP)
30.	232-41-25430	[2]	O-RING (OP)
30.	232-41-25440	[2]	RING (OP)
30.	232-41-25560	[1]	SEAL (OP)
31	234-41-05010	[1]	SERVICE KIT,STEERING BOOSTER
31.	234-41-14320	[1]	O-RING
31.	234-41-14350	[4]	PACKING
31.	234-41-14360	[1]	SEAL
31.	234-41-14470	[1]	O-RING
31.	234-41-14520	[1]	O-RING
31.	234-41-14540	[1]	RING
31.	234-41-14550	[1]	RING
31.	234-41-14560	[1]	O-RING
31.	234-41-14570	[1]	O-RING
31.	234-41-14580	[1]	RING
31.	234-41-14590	[1]	RING
31.	234-41-14660	[1]	O-RING
31.	234-41-14620	[1]	PIN
31.	234-41-15220	[1]	PIN
31.	234-41-15210	[1]	WASHER
31.	234-41-15230	[1]	PIN
31.	234-41-14910	[1]	PIN
32	232-40-05110	[1]	SERVICE KIT,STEERING CYLINDER
32.	232-40-53640	[1]	U-PACKING
32.	232-40-53650	[1]	SLEEVE
32.	07016-00256	[1]	SEAL
32.	232-40-53670	[1]	O-RING
32.	232-40-53710	[1]	RING
32.	232-40-53720	[1]	RING
32.	07000-13042	[1]	O-RING
33	232-46-05010	[1]	SERVICE KIT,BALL JOINT
33.	232-46-13170	[8]	SHIM, 0.29MM
34	232-60-05010	[1]	SERVICE KIT,HYD. PUMP
34	232-60-05012	[1]	SERVICE KIT,HYD. PUMP
34.	232-60-11131	[2]	GASKET
35	232-60-05021	[1]	SERVICE KIT,HYD. PUMP
36	232-60-05031	[1]	SERVICE KIT,HYD. CONTROL VALVE
36	232-60-05034	[1]	SERVICE KIT,HYD. CONTROL VALVE
36.	232-60-91290	[7]	SEAL
36.	232-60-91550	[7]	SEAL
36	700-13-05010	[1]	SERVICE KIT,CONTROL VALVE
36.	07000-13032	[16]	O-RING
36.	07000-13040	[4]	O-RING
36.	700-13-31160	[1]	O-RING
36.	07000-13038	[1]	O-RING
36.	07000-12014	[5]	O-RING
36.	700-12-31390	[6]	U-PACKING
36.	07016-00226	[3]	SEAL
36	700-14-05010	[1]	SERVICE KIT,CONTROL VALVE (4-SPOOL)
37	700-10-05010	[2]	SERVICE KIT,RELIEF VALVE
37.	07000-12015	[1]	O-RING
37.	07000-13022	[1]	O-RING OEM
37.	07000-02012	[1]	O-RING
38	232-60-05043	[1]	SERVICE KIT,HYD. TANK
38	232-60-05042	[1]	SERVICE KIT,HYD. TANK
38.	232-60-13131	[1]	GASKET
39	232-60-05055	[1]	SERVICE KIT,PIPING (HIGH)
39	232-60-05054	[1]	SERVICE KIT,PIPING (HIGH)
39	232-60-05053	[1]	SERVICE KIT,PIPING (HIGH)
39	232-60-05052	[1]	SERVICE KIT,PIPING (HIGH)
39.	07002-12034	[14]	O-RING
39.	07000-03017	[2]	O-RING
39.	07002-12434	[12]	O-RING
39.	07000-03020	[8]	O-RING OEM
39.	07000-15075	[3]	O-RING
39.	07000-05075	[3]	O-RING
40	232-60-05070	[1]	SERVICE KIT,PIPING (LOW)
40	232-60-05069	[1]	SERVICE KIT,PIPING (LOW)
40	232-60-05068	[1]	SERVICE KIT,PIPING (LOW)
40	232-60-05067	[1]	SERVICE KIT,PIPING (LOW)
40.	07000-05100	[1]	O-RING
40.	07000-03028	[2]	O-RING
40.	07000-03052	[1]	O-RING
40.	07000-15100	[1]	O-RING
40.	07000-13035	[2]	O-RING
40.	07000-13045	[2]	O-RING
40.	07000-13020	[2]	O-RING OEM
40.	07000-13017	[2]	O-RING
40.	07000-13050	[1]	O-RING
40.	07000-13052	[1]	O-RING
40.	07002-13634	[1]	O-RING
40.	07000-13030	[2]	O-RING
40.	07002-14234	[1]	O-RING
41	232-60-05080	[1]	SERVICE KIT,HYD. FILTER
41.	07000-13078	[1]	O-RING OEM
42	232-60-05092	[1]	SERVICE KIT,PILOT CHECK VALVE
42	232-60-05091	[1]	SERVICE KIT,PILOT CHECK VALVE
42	232-60-05090	[1]	SERVICE KIT,PILOT CHECK VALVE
42.	07002-13034	[8]	O-RING
