233-71-00011 2337100011 Blade Lift Cylinder Seal Kit For Komatsu
Price:
Negotiable
MOQ:
Accept trial order
Delivery Time:
3-5 days after payment received(public holiday excluded)
Brand:
SUNCAR
Product Description
233-71-00011 2337100011 Blade Lift Cylinder Seal Kit For Komatsu For KOMATSU GD31-1 GD31-3H
| Name | 233-71-00011 2337100011 Blade Lift Cylinder Seal Kit |
| Type | Blade Lift Cylinder Seal Kit |
| Pressure | 0~60MPa |
| Temperature | -45℃ +200℃ |
| Speed | 15m/s |
| Medium | Hydraulic oil, fire retardant liquid, water and others |
| Features | Pressure & Oil Resistant |
| Material | IDI |
Part Numbers of Cylinder Service Kits:
| 707-99-96223 | 707-99-75410 | 707-98-71020 |
| 707-99-96170 | 707-99-75440 | 707-99-56510 |
| 707-99-77610 | 707-99-43570 | 707-99-74440 |
| 707-99-77611 | 707-99-43500 | 707-99-74450 |
| 707-99-77612 | 707-99-84400 | 707-98-74100 |
| 707-99-77660 | 707-99-84440 | 707-99-67690 |
| 707-99-41100 | 707-99-43590 | 707-99-47510 |
| 707-99-03420 | 707-99-84450 | 707-99 -64080 |
| 707-99-32100 | 707-99-84470 | 707-99-43170 |
| 707-99-53500 | 707-99-77090 | 707-99-44220 |
| 707-99-43110 | 707-99-44060 | 203-63-52340 |
| 707-99-43520 | 707-99-77630 | 203-63-62340 |
| 418-63-05000 | 707-99-47830 | 203-63-72340 |
| 707-99-53100 | 707-99-77600 | 205-63-54101 |
| 707-99-62020 | 707-99-46620 | 205-63-64101 |
| 707-99-53150 | 707-99-86600 | 205-63-74101 |
| 707-99-14750 | 707-99-85900 | 205-63-79300 |
| 707-99-14770 | 707-99-85920 | 205-63-79310 |
| 707-99-62110 | 707-99-66210 | 707-99-76010 |
| 707-99-53170 | 707-99-96200 | 707-99-85380 |
| 707-99-62120 | 707-99-96201 | 707-98-02420 |
| 707-99-64120 | 707-99-96130 | 708-1S-00410 |
| 707-99-24280 | 707-99-73010 | 707-99-15710 |
| 707-99-64520 | 707-98-62131 | 707-98-22020 |
Parts on group :
| Pos. | Part No | Qty | Parts name |
| 233-71-00011 | [2] | CYLINDER AS'Y | |
| 1. | 233-71-11111 | [1] | CYLINDER |
| 2. | 233-71-11211 | [1] | COVER |
| 3. | 07000-03092 | [1] | O-RING |
| 4. | 01040-31660 | [4] | BOLT |
| 5. | 01602-01648 | [4] | WASHER |
| 6. | 131-60-16241 | [1] | BUSHING |
| 7. | 131-60-16250 | [1] | RING |
| 8. | 131-60-16260 | [1] | RETAINER |
| 9. | 131-60-16271 | [1] | U-RING |
| 10. | 131-60-16281 | [1] | HEEL |
| 11. | 131-60-16290 | [1] | BUSHING |
| 12. | 233-71-11231 | [1] | GLAND |
| 13. | 01040-31240 | [2] | BOLT |
| 14. | 01602-01236 | [2] | WASHER |
| 15. | 130-09-11631 | [2] | SEAL |
| 16. | 233-71-11311 | [1] | ROD |
| 17. | 232-71-12130 | [1] | CAP |
| 18. | 232-71-11340 | [2] | SHIM, 0.2MM |
| 19. | 01000-31665 | [2] | BOLT |
| 20. | 01500-31613 | [2] | NUT |
| 22. | 233-71-11321 | [1] | PISTON |
| 23. | 233-71-11270 | [2] | RING |
| 24. | 233-71-11290 | [2] | HEEL |
| 25. | 233-71-11280 | [2] | U-RING |
| 26. | 233-71-11371 | [2] | HOLDER |
| 27. | 07000-03020 | [1] | O-RING OEM |
| 28. | 01513-32426 | [1] | NUT |
| 29. | 04050-05045 | [1] | PIN |
| 30. | 07020-00675 | [1] | FITTING |
| 31. | 233-71-11132 | [1] | TUBE |
| 32. | 07232-00522 | [1] | ELBOW |
| 33. | 07000-03022 | [1] | O-RING OEM |
| 34. | 07239-02410 | [1] | NUT |
| 35. | 07282-02288 | [1] | CLAMP |
| 36. | 01040-31020 | [2] | BOLT |
| 37. | 01602-01030 | [2] | WASHER |
| 38. | 233-71-11142 | [1] | TUBE |
| 45 | 233-71-11510 | [2] | YOKE |
| 46 | 01000-31230 | [8] | BOLT |
| 233-71-00050 | [4] | COVER AS'Y | |
| 48. | 233-71-11530 | [1] | COVER |
| 49. | 233-71-11540 | [1] | BUSHING |
| 51 | 01511-34525 | [2] | NUT |
| 52 | 233-71-11520 | [2] | WASHER |
| 53 | 04050-08075 | [2] | PIN |
| 53 | 233-71-00041 | [1] | BRACKET AS'Y |
| 54. | 233-71-11411 | [1] | BRACKET |
| 55. | 233-71-11421 | [1] | BRACKET |
| 55 | 233-71-11430 | [1] | JOINT |
| 56. | 233-71-11450 | [8] | SHIM, 0.5MM |
| 57. | 04020-01228 | [2] | PIN |
| 58. | 01000-31875 | [4] | BOLT |
| 59. | 01500-31816 | [4] | NUT |
| 60. | 01602-01854 | [4] | WASHER |
| 61. | 233-71-11440 | [4] | BUSHING |
| 62. | 07020-00000 | [2] | FITTING |
