91ER-20050 91ER20050 Remote Control Lever Seal Kit For Excavator HYUNDAI
Price:
Negotiable
MOQ:
10 Sets
Delivery Time:
3-7 days after payment received(Public Holiday Excluded)
Brand:
SUNCAR
Product Description
91ER-20050 91ER20050 Remote Control Lever Seal Kit For Excavator HYUNDAI
Description: This is a seal kit belong to pilot valve seal kit for HYUNDAI.
SUNCAR is committed to provide the best products and services to all of you.
| Product name | 91ER-20050 91ER20050 Remote Control Lever Seal Kit For Excavator HYUNDAI |
| Brand | SUNCAR |
| Fit brand | HYUNDAI |
| Part number | 91ER-20050 91ER20050 |
| Color | As per standard color |
| Compatible model |
3-Series Crawler Excavator R160LC3 |
| Feature |
Durability,hard-wearing,higher-toughness,seal performance |
| Temperature |
NBR(-40~120°C),FFKM(-20~320°C) FKM(-20~200°C),Silicone (-70~220°C) EPDM(-50~150°C),PU(-40~90°C) |
| Part name | Remote control lever seal kit;Pilot valve seal kit |
| Gross weight of single product |
0.500 kg |
| Package | PP bag, carton, wooden box, or as required |
| AppliC-A-Tion | HYUNDAI |
| AppliC-A-Tion industry | Machinery repair store;Excavator HYUNDAI |
| Section code | Working hydraulics / Main control valve, boom and bucket and travel |
| Section code | Working hydraulics |
| MOQ | 10 sets |
| Type | Hydraulic control valve seal kit |
| Payment terms | L/C, D/A, D/P, T/T, Western Union, |
| Packaging | Nuetral packaging or OEM packaging |
| Shipping mode | By air, by sea, by express |
| By Express | Post FedEx , UPS,DHL,TNT etc |
| Forwarder | Your local forwarder or we find for you |
| Quality | Stable quality,OEM standard,Genuine/Aftermarket |
| Loading port |
Huangpu port,China |
| Pos. | Part No | Qty | Parts name |
| *. | 31N6-25200 | [1] | RCV SUB ASSY-LH |
| *. | 31N6-25210 | [1] | RCV SUB ASSY-RH |
| *. | 31N6-27200 | [1] | RCV LEVER SUB ASSY-LH |
| *. | 31N6-27210 | [1] | RCV LEVER SUB ASSY-RH |
| *. | 31N6-20061 | [1] | RCV LEVER-LH |
| *. | 31N6-20071 | [1] | RCV LEVER-RH |
| 1 | XKAY-00077 | [1] | CNH |
| 2 | XKAY-00065 | [4] | PLUG |
| 3 | XKAY-00064 | [1] | PLUG |
| K4. | XKAY-00063 | [1] | O-RING |
| *-1. | XKAY-00615 | [1] | SPOOL KIT |
| 5 | XKAY-00062 | [4] | SPOOL |
| 6 | XKAY-00061 | [4] | SHIM |
| 7 | XKAY-00060 | [4] | SPRING |
| 8 | XKAY-00436 | [4] | SEAT-SPRING(1,3) |
| 9 | XKAY-00058 | [4] | STOPPER |
| 10 | XKAY-00078 | [4] | SPRING |
| 11 | XKAY-00056 | [4] | PLUG |
| K12. | XKAY-00055 | [4] | SEAL-ROD |
| K13. | XKAY-00054 | [4] | O-RING |
| 14 | XKAY-00052 | [4] | ROD-PUSH(1,3) |
| *-2. | XKAY-00608 | [4] | PLUG KIT(1,3) |
| 11 | XKAY-00610 | [4] | PLUG |
| K12. | XKAY-00611 | [4] | SEAL-ROD |
| K13. | XKAY-00054 | [4] | O-RING |
| 14 | XKAY-00052 | [4] | ROD-PUSH(1,3) |
| 15 | XKAY-00075 | [1] | PLATE |
| 16 | XKAY-00074 | [1] | BUSHING |
| 17 | XKAY-00049 | [1] | JOINT ASSY |
| 18 | XKAY-00073 | [1] | SWASH PLATE |
| 19 | XKAY-00047 | [1] | NUT-HEX |
| 20 | XKAY-00046 | [1] | NUT |
| *-3. | XKAY-00617 | [1] | HANDLE KIT(L) |
| *-3. | XKAY-00616 | [1] | HANDLE KIT(R) |
| 21 | XKAY-00044 | [1] | CONNECTOR-HANDLE |
| K22. | XKAY-00045 | [1] | O-RING |
| 23 | XKAY-00043 | [1] | NUT |
| 24 | XKAY-00042 | [1] | INSERT |
| 25 | XKAY-00041 | [1] | BOOT |
| N26. | XKAY-00040 | [1] | HANDLE-LH |
| N26. | XKAY-00076 | [1] | HANDLE-RH |
| 27 | XKAY-00039 | [1] | SWITCH ASSY |
| 28 | XKAY-00038 | [1] | SCREW |
| 29 | XKAY-00037 | [1] | SWITCH ASSY |
| 30 | XKAY-00036 | [1] | COVER-SWITCH |
| 40 | XKAY-00072 | [1] | BOOT |
| 41 | X500-110001 | [5] | CONNECTOR-ORFS |
| 42 | 31N6-25060 | [1] | FILTER-LAST GUARD |
| 43 | S631-011004 | [6] | O-RING |
| 44 | S621-011001 | [6] | O-RING |
| K. | 91ER-20050 | [1] | SEAL KIT |
| K. | 91ER-20051 | [1] | SEAL KIT |
| N. | @ | [1] | NOT INDIVIDUALLY SUPPLIED |
