2438U588R110 Piston Rod Seal Repair Kit Use In Cylinder KOBELCO K909-A
2438U588R110 Piston Rod Seal Repair Kit Use in Cylinder KOBELCO K909-A
Description: This oil seal CA1289170 128-9170 1289170 appliC-A-Ted in motor,pump,swing device,excavator parts and so on.Oil seals are used to protect shafts and bearings from ingress of dirt and foreign matter and egress of oil or grease. An oil seal generally consists of an outer circular metal part and an inner flexible member that does the actual sealing and is bonded to the metal part by chemical adhesive agents.
Products Details :
| Product name | 2438U588R110 Piston Rod Seal Repair Kit Use in Cylinder KOBELCO K909-A |
| Material | PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ |
| Part number | 2438U588R110 |
| Temp. | -40~120°C |
| Relative sizes | Standard size |
| Place original | Guangzhou,China |
| Advantages |
The resistance against oil and fuels is better than other types; The only highly elastic rubber whice is resistance to aromatci and chlornated hydrocarbon; Exccllcent hC-A-T resistance; Exccllcent weather and ozonc resistance; Exccllcent acid resistance; Low swelling in water. |
| AppliC-A-Tion |
All types of rotative appliC-A-Tions; Machine tools;Agriculture |
| Loading port | Huangpu port,China |
| Payment | L/C, D/A, D/P, T/T, Western Union, |
| Medium | Hydraulic oil, flame retardant liquid, water and others |
| Type | Hydraulic oil seal;BABSL/BAUM5SLX7 CFW oil seal |
Compatible Models:
| K907 | K907LC |
| K909A | K909LC |
Relative Part Numbers:
| Pos. | Part No | Qty | Parts name |
| . . | 2438U568F2 | [1] | BUCKET CYLINDER |
| 1 | 2438U568S1 | [1] | TUBE |
| 2 | 2438U588S2 | [2] | BUSHING |
| 3 | NSS | [1] | NOT SOLD SEPARAT |
| 4 | 2438U588S4 | [1] | PISTON |
| 5 | R45P0049D3 | [1] | SEAL |
| 6 | 45Z91D46 | [1] | O-RING |
| 7 | R45T0014D9 | [4] | WEAR RING |
| 8 | ZD12G06000 | [1] | O-RING,59.40mm ID x 65.60mm OD x 3.10mm |
| 9 | ZD85G06000 | [2] | BACK-UP RING |
| 10 | 2438U588S10 | [1] | NUT |
| 11 | 2438U588S11 | [1] | LOCKING RING |
| 12 | 2438U588S12 | [1] | PLATE |
| 13 | 2438U588S13 | [1] | SPRING |
| 14 | 2438U588S14 | [1] | AIR CONDITIONER |
| 15 | 2438U321S15 | [1] | BUSHING |
| 16 | 2418U112D74 | [1] | CLIP |
| 17 | ZD12P14000 | [2] | O-RING |
| 18 | 2438U308S18 | [2] | BACK-UP RING |
| 19 | 2438U588S19 | [1] | O-RING |
| 20 | R45P0050D10 | [1] | SEAL |
| 21 | 45Z91D117 | [1] | O-RING |
| 22 | 2438U322S33 | [1] | PACKING |
| 23 | 2438U321S33 | [1] | COVER |
| 24 | 2438U552S24 | [1] | SEAL |
| 25 | 2438U588S25 | [1] | O-RING |
| 26 | ZW13H16000 | [12] | WASHER |
| 27 | ZS23C16075 | [12] | SCREW,Hex Socket Head |
| 28 | 2438U568S31 | [4] | DUST CAP |
| . . | 2438U568R100 | [1] | REPAIR KIT |
| . . | 2438U588R110 | [1] | REPAIR KIT |
| . . | 2438U568R120 | [1] | SEAL KIT |
