707-98-14610 7079814610 Arm Cylinder Service Kit for PC10-7 PC25R-8
707-98-14610 7079814610 Arm Cylinder Service Kit for PC10-7 PC25R-8
Description: This is a set of arm cylinder seal kit for Excavator KOMATSU PC10-7 PC30MR-1 PC30UU-3 etc.
| Product name | 707-98-14610 7079814610 Arm Cylinder Service Kit for PC10-7 PC25R-8 |
| Brand name | SUNCAR |
| Part numbers | 707-98-14610 7079814610 |
| MOQ | Accept trial order |
| Feuture |
Excellent durability and flexibility in using. |
| Payment | Paypal,T/T, Western Union, ,Bank Transfer |
| Paking details | PP bag inside,carton box outside. |
| Loading Port | Huangpu port,China |
| Shopping mode |
By air, by sea, by express ( FedEx , UPS,DHL,TNT etc.) |
|
CertifiC-A-Tion |
ISO9001 |
| Consist of | Dust seal,O-ring,piston rod,wear ring;back-up ring |
|
Availability |
In stock |
| Fits equipment | KOMATSU |
Compatible Models:
| PC10-7 | PC25R-8 | PC30MR-1 |
| PC10N-7 | PC27MR-1 | PC30R-7 |
| PC15-3 | PC27MRX-1 | PC30UU-3 |
| PC20-7 | PC27R-8 | PC35MR-1 |
| PC20MR-1 | PC28UU-3 | PC38UU-3 |
| PC20MRX-1 | PC38UU-2 | PC38UUM-2 |
Hydraulic cylinder seal kits are used to seal the gap between different parts of the hydraulic cylinder. The function of
hydraulic cylinder seal kits is to prevent oil leakage, to assure the working pressure of the hydraulic system, to
maintain its power.
Boom Cylinder seal kit is, as the name suggests, fitted into the boom cylinder.
There are regularly three cylinders for the excavator, boom cylinder, arm cylinder, bucket cylinder.
Arm cylinder is the top one, and it's usually be called as top cylinder;
The bucket cylinder is the one that connects and controls the bucket.
Boom cylinder is the one (or the two) near the cabin. Usually, there is one piece boom cylinder for the small excavator under 10-tun; the bigger
excavator's two pieces boom cylinders. But there is an exception too when the driver will remove one piece for a special purpose, say at some
particular working place, it is convenient to work by one cylinder. Soft remind: all refit job should be operated by an experienced technician
Parts on Group Arm Cylinder:
| K-1 | 707-98-25520 | SERVICE KIT,BOOM CYLINDER | 1 |
| K-1 | 707-98-25600 | SERVICE KIT | 1 |
| 07145-00050 | • SEAL,DUST | 2 | |
| 707-51-50211 | • PACKING,ROD | 1 | |
| 176-63-92240 | • SEAL,DUST | 1 | |
| 07000-12085 | • O-RING | 1 | |
| 07000-12085 | • O-RING | 2 | |
| 07146-02086 | • RING | 1 | |
| 07146-02086 | • RING,BACK-UP | 2 | |
| 707-35-52690 | • RING,BACK-UP | 1 | |
| 07000-02090 | • O-RING | 1 | |
| 07145-00050 | • SEAL,DUST | 2 | |
| 707-44-90180 | • RING,PISTON | 1 | |
| 07156-00912 | • RING,WEAR | 1 | |
| K-2 | 707-98-25190 | SERVICE KIT,ARM CYLINDER | 1 |
| 07145-00045 | • SEAL,DUST | 2 | |
| 707-51-50211 | • PACKING,ROD | 1 | |
| 176-63-92240 | • SEAL,DUST | 1 | |
| 07000-12075 | • O-RING | 1 | |
| 07146-02076 | • RING,BACK-UP | 2 | |
| 07000-12075 | • O-RING | 1 | |
| 707-35-52750 | • RING,BACK-UP | 1 | |
| 07000-02080 | • O-RING | 1 | |
| 07145-00045 | • SEAL,DUST | 2 | |
| 707-44-80180 | • RING,PISTON | 1 | |
| 07156-00810 | • RING,WEAR | 1 | |
| K-3 | 707-98-24180 | SERVICE KIT,OFFSET CYLINDER | 1 |
| 07145-00040 | • SEAL,DUST | 2 | |
| 707-51-45210 | • PACKING,ROD | 1 | |
| 112-63-15370 | • SEAL,DUST | 1 | |
| 07000-12075 | • O-RING | 1 | |
| 07146-02076 | • RING,BACK-UP | 1 | |
| 07000-02080 | • O-RING | 1 | |
| 07145-00040 | • SEAL,DUST | 2 | |
| 707-44-80180 | • RING,PISTON | 1 | |
| 07156-00810 | • RING,WEAR | 1 | |
| K-4 | 707-98-14610 | SERVICE KIT,BUCKET CYLINDER | 1 |
| 07145-00035 | • SEAL,DUST | 2 | |
| 707-51-40210 | • PACKING,ROD | 1 | |
| 198-63-75190 | • SEAL,DUST | 1 | |
| 07000-12065 | • O-RING | 1 | |
| 07146-02066 | • RING,BACK-UP | 1 | |
| 07000-02070 | • O-RING | 1 | |
| 07145-00035 | • SEAL,DUST | 2 | |
| 707-44-70180 | • RING,PISTON | 1 | |
| 07156-00710 | • RING,WEAR | 1 | |
| K-5 | 707-98-24570 | SERVICE KIT,BLADE CYLINDER | 1 |
| 07145-00050 | • SEAL,DUST | 2 | |
| 707-51-45210 | • PACKING,ROD | 1 | |
| 112-63-15370 | • SEAL,DUST | 1 | |
| 07000-12085 | • O-RING | 1 | |
| 07146-02086 | • RING,BACK-UP | 1 | |
| 07000-02090 | • O-RING | 1 | |
| 07145-00050 | • SEAL,DUST | 2 | |
| 707-44-90180 | • RING,PISTON | 1 | |
| 07156-00912 | • RING,WEAR | 1 | |
| K-6 | 707-98-24550 | SERVICE KIT,TILT CYLINDER | 1 |
| 07000-03035 | • O-RING | 4 | |
| 112-63-15370 | • SEAL,DUST | 1 | |
| 707-51-45210 | • PACKING,ROD | 1 | |
| 07000-02090 | • O-RING | 1 | |
| 07000-12085 | • O-RING | 1 | |
| 07146-02086 | • RING,BACK-UP | 1 | |
| 707-44-90180 | • RING,PISTON | 1 | |
| 07156-00912 | • RING,WEAR | 1 | |
| K-7 | 707-98-24610 | SERVICE KIT,BLADE LIFT CYLINDER | 1 |
| 07145-00050 | • SEAL,DUST | 4 | |
| 707-51-45210 | • PACKING,ROD | 1 | |
| 112-63-15370 | • SEAL,DUST | 1 | |
| 07000-12090 | • O-RING | 1 | |
| 707-35-52780 | • RING,BACK-UP | 1 | |
| 07000-02095 | • O-RING | 1 | |
| 707-44-95180 | • RING,PISTON | 1 | |
| 707-39-95110 | • RING,WEAR | 1 | |
| K-8 | BK301Z-SK | SERVICE KIT,BREAKER | 1 |
| BKE1022065 | • O-RING | 1 | |
| BKE3110048 | • U-PACKING | 3 | |
| BKE3120053 | • U-PACKING | 3 | |
| BKE1022070 | • O-RING | 1 | |
| BKE1012020 | • O-RING | 2 | |
| BKE1022040 | • O-RING | 2 | |
| BKE2122040 | • RING,BACK-UP | 1 | |
| BKE1022040 | • O-RING | 4 | |
| BKE2122040 | • RING,BACK-UP | 5 | |
| BKE1012020 | • O-RING | 1 | |
| BKE1022085 | • O-RING | 1 | |
| BKR911101 | • VALVE | 1 | |
| BKE1022025 | • O-RING |
