TZ511B9000-01 Seal Kit For Travel Motor Final Drive PC45-1 PC50UU-1 PC50UU-2
Price:
Negotiable
MOQ:
Accept trial order
Delivery Time:
3-7 Days After Payment Received(Public Holiday Excluded)
Brand:
SUNCAR
Product Description
TZ511B9000-01 Seal Kit for Travel Motor Final Drive PC45-1 PC50UU-1 PC50UU-2
Description:
This is a set of seal kiot for travel motor and final drive.
The travel motor provides the power that the final drive transforms into torque. Then torque is transferred to the sprocket, which turns the wheel
or track.The power comes from the hydraulic system.When you find the travel lose power, there might be because the oil leakage caused to the
travel motor.In other words, the travel motor seal kit prevents oil from leaking and maintains power.
| Product name | TZ511B9000-01 Seal Kit for Travel Motor Final Drive PC45-1 PC50UU-1 PC50UU-2 |
| Brand name | SUNCAR |
| OEM number | TZ511B9000-01 |
| Fits model | PC45-1; PC50UU-1 ; PC50UU-2 |
| Group | Final drive seal kit |
| Make up | O-ring;Dust seal,U-packing;buffer ring |
| MOQ | Accept trial order |
| Function | Dust proof, Shaft seal,high and low temperature resistance |
| Material |
PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ |
| Temp. | FKM(-20~200°C) , Silicone (-70~220°C) |
| Temp. | EPDM(-50~150°C), PU(-40~90°C) |
| Temp. | NBR(-40~120°C), FFKM(-20~320°C) |
| Supply alility | 550 sets per week |
| Condition | 100 % new,brandnew |
| Feature | High efficiency, Long life |
| Transport mode | Air, Sea, Express ( FedEx , UPS,DHL,TNT etc.) |
| CertifiC-A-Tion | ISO9001 |
| Market | North America, South America, Western Europe, Eastern Europe, Eastern Asia, Southeast Asia, Middle East, Africa, Oceania, Worldwide |
| Working temperature | -30°~+110°C -25°~+220°C (Depend on material of O-ring) |
| Working speed | ≤4m/s |
| Size specifiC-A-Tion | Standard size |
| AppliC-A-Tion | Breaker;Resell store;Construction machinery works |
| Stock | In rich stock |
| Style |
Hydraulic seal kit;Travel motor seal kit. |
Advantages:
Longer duration,higher quality.
More reliable performance.
Lower maintenance cost.
Enhancing the international quality.
Exceeding value with the local price.
Relative Parts:
| Pos. | Part No | Qty | Parts name |
| 20T-60-72120 | [2] | TRAVEL MOTOR ASS'Y | |
| TZ512B1102-00 | [1] | SPINDLE KIT | |
| 1 | TZ512B1132-00 | [1] | SPINDLE ASS'Y |
| 2 | TZMB700-060 | [1] | PLUG |
| 3 | TZ550A1019-00 | [3] | BOLT,REAMER |
| 4. | 07000-11007 | [1] | O-RING (KIT) |
| 5. | TZJW1516-G26-9 | [1] | O-RING (KIT) |
| 6. | TZ510B1001-01 | [1] | HUB |
| 7. | TZES100-178-A | [1] | SEAL,FLOATING (KIT) |
| 8. | TZ550A1010-01 | [1] | PIECE,DISTANCE |
| 9. | 07000-15210 | [1] | O-RING (KIT) |
| 10. | TZ510B1021-00 | [2] | BEARING,BALL |
| 11. | TZ310B1017-00 | [30] | PIN |
| 12. | TZ510B1011-00 | [1] | RING |
| TZ510B1104-00 | [1] | RV GEAR ASS'Y (2 PIS) | |
| 13 | TZ510B1204-00 | [1] | RV GEAR KIT |
| 14 | TZ510B1009-00 | [3] | SHAFT,CRANK |
| 15 | TZ310B1022-01 | [6] | BEARING,ROLLER |
| 16 | TZ850A1023-00 | [6] | BEARING,NEEDLE |
| 17. | TZ310B1013-00 | [3] | SNAP RING KIT |
| 18. | TZ550A1014-00 | [3] | PIECE,DISTANCE |
| 19. | TZ511B1107-00 | [1] | SPUR GEAR KIT |
| 20. | 04064-02212 | [3] | RING,SNAP |
| 21 | TZ511B1006-01 | [1] | GEAR,INPUT |
| 22 | 04064-01510 | [1] | RING,SNAP |
| 23 | TZ510B1008-01 | [1] | COVER |
| 24 | 07000-15200 | [1] | O-RING (KIT) |
| 25 | TZ550A1018-00 | [1] | RING |
| 26 | TZGM3-8 | [3] | PLUG |
| TZ511B9000-01 | [1] | SEAL KIT | |
| TZJB2401-P22-9 | [2] | O-RING | |
| 07000-12012 | [2] | O-RING | |
| TZ15Z-17-35-8 | [1] | SEAL,OIL |
