ODM SV 400 1080mm Wall Mounted Refrigeration Unit
ODM SV 400 1080mm Wall Mounted Refrigeration Unit
product Introductionn:
Condition:New, New
Applicable Industries:Cold Storage Room Freezer Room, Cold Storage Room Freezer Room
Type:COMPRESSOR
Place of Origin:Singapore
Brand Name:Thermo king, Thermo king
Model Number:SV-400
Color:White
MOQ:1
Keyword:Refrigerator System For Truck
.SV-400
.SV-600
.SV-700
.SV-800 . SV-1000
ODM SV 400 1080mm Wall Mounted Refrigeration Unit
| Temp.Range | -25°C~+30°C | ||||||
| Refrigerant | R-404A | ||||||
| Charge (kg) | 1.8 | 2.5 | 2.5 | 2.6 | 2.6 | ||
| Compressor | |||||||
| Model | TK16 | TK16 | TK21 | TK21 | TK21 | TK31 | |
| Number of Cylinder | 6 | 6 | 10 | 10 | 10 | 10 | |
| Displacement (cm3) | 163 | 163 | 215 | 215 | 215 | 313 | |
| Cooling Capacity (W) | A.T.P. U.N. Standard @30°C (Ambient) | ||||||
| Engine power | 0°C | 4,360 | 5,060 | 5,500 | 6,700 | 7,500 | 8,500 |
| -20°C | 2,350 | 2,620 | 2,750 | 3,200 | 4,100 | 4,550 | |
| Electric standby (3phase) | 0°C | 3,800 | 4,720 | 5,780 | 6,570 | 6,570 | |
| -20°C | 1,860 | 2,460 | 2,900 | 3,400 | 3,400 | ||
| Electric standby (1phase) | 0°C | 3,300 | 3,960 | ||||
| -20°C | 1,500 | 1,860 | |||||
| Cooling capacity (W) | A.R.I. U.S. Standard @38°C (Ambient) | ||||||
| Engine power | 2°C | 4,140 | 4,900 | 5,225 | 6,365 | 7,300 | 8,080 |
| -18°C | 2,250 | 2,570 | 2,670 | 3,040 | 4,000 | 4,320 | |
| Electric standby (3phase) | 2°C | 3,500 | 4,350 | 5,490 | 6,200 | 6,200 | |
| -18°C | 1,780 | 2,410 | 2,760 | 3,260 | 3,260 | ||
| Electric standby (1phase) | 2°C | 3,080 | 3,700 | ||||
| -18°C | 1,300 | 1,730 | |||||
| Evaporator blower performance | |||||||
| Flow rate (m3/h) (@0static pressure) | 1500 | 2500 | 2500 | 3000 | 3000 | ||
| Velocity ( m/s) | 3.3 | 3 | 3 | 3.5 | 3.5 | ||
| Electric standby | |||||||
|
Compressor |
semi-hermetic (3phase:151CC;1phase:129CC) |
semi-hermetic (3phase:151CC;1phase:129CC) |
semi-hermetic (206CC) |
semi-hermetic (206CC) |
semi-hermetic (206CC) |
||
|
|
|||||||
Thermo King robust compressor
High reliability, reduce failure rate Low life cycle cost
SV-Series Dimension(mm):
Packaging & Shipping
Before all finished products are sent out .we will aslo carry out the standard fastness test .After all the tests are qualified ,We will deliver the goods to the Port or location designated by the customer
