Tools & Hardware Abrasives Abrasive Tools
China T42 230x3x22.23mm/9x1/8x7/8

T42 230x3x22.23mm/9x1/8x7/8" Metal Cutting Abrasive Blade

Price Negotiable
Price: US$0.4-0.5 per piece
MOQ: 10000
Delivery Time: 30-60 Days
Brand: Grassland
Product Description



Cutting Discs 230x3x22.23mm/9x1/8x7/8" Metal Cutting Abrasive Blade



Description


• Type 27 - Depressed Center
• Dimensions = 7"x 1/8" x 7/8"
• Max RPM = 8,500
• Material = Heat-treated Aluminum Oxide
• Hardness = (R) Hard

• Optimum angle for use 90°

• Very uniform, high density grain structure is extremely durable and self sharpening for long life and cooler cut
• Extremely fast stock removal on hard metals with minimal pressure
• manufactured with premimun abrasive grain, is designed to outlast standard aluminum oxide wheels
• Special bonding formula allows for very fast stock removal on many types of metals
• Designed to provide very long life for fewer wheel changes and less downtime
• All sizes reinforced with the highest quality fiberglass for maximum safety and performance



Selecting the right cut-off wheel ensures freedom from burn and distortion and is the best way to save time and consumables. Correct cutting produce specimens which are in perfect condition for the next preparation steps.





Applications



There are many applications for cut-off wheels and abrasive saw blades. used in the production of automotive parts, ceramics and glass, ophthalmic and optical products, plastics and composites, or semiconductors and electronics. Important considerations include rotary speed, outer diameter (OD), and bore size or shank diameter.




Cutting wheel information:
Product Name

9inch grinding disk for metal

 Abrasive Aluminum oxide and corundum
Hardness R Grade Net Grade Reinforced fiberglass
Max working speed



80 m/s



 OEM Service Acceptable
R.P.M 6650 Package

Kraft Carton and Pallet


Grit size 46#,24#,30# HS Code 68042210

Certificate



MPA EN12413,ISO9001



 Loading Port Tianjin or else

1.Super thin cutting disc for metal stainless steel

Description of goods Item No Specification Unit PCS/CTN N.W./G.W.(KGS) CARTON SIZE(CM)
Flat cutting disc for inox/Alu 80m/s FSC0751009 T41-75X1.0X9.5MM PC 800 9/10 34*17*17
FSC0751695 T41-75X1.6X9.5MM PC 800 14/15 34*20*17
FSC1001016 T41-100X1.0X16MM PC 400 8.5/9.5 22*22*15.7
FSC1002016 T41-100X2.0X16MM PC 400 15/16 29.7*22*22
FSC1151022 T41-115X1.0X22.2MM PC 400 11/12 24.5*24.5*15.7
FSC1151622 T41-115X1.6X22.2MM PC 400 14/15 24.5*24.5*19.2
FSC1152022 T41-115X2.0X22.2MM PC 200 9.5/10.5 24.5*24.5*13.2
FSC1251022 T41-125X1.0X22.2MM PC 400 13/14 26.5*25.6*15.7
FSC1251622 T41-125X1.6X22.2MM PC 400 17/18 26.5*25.6*19.2
FSC1252022 T41-125X2.0X22.2MM PC 200 10.5/11.5 26.5*26.5*13.2
FSC1501622 T41-150X1.6X22.2MM PC 200 12/13 32*32*11.7
FSC1502022 T41-150X2.0X22.2MM PC 200 16.5/17.5 32*32*13.2
FSC1801622 T41-180X1.6X22.2MM PC 200 20/21 37.5*19*22.7
FSC1802022 T41-180X2.0X22.2MM PC 100 10.5/11 37.5*19*13.2
FSC2301622 T41-230X1.6X22.2MM PC 50 8/9 24*24*11.7
FSC2302022 T41-230X2.0X22.2MM PC 100 18.5/19.5 24*24*25.7





2-Type 42 depressed center grinding discs wheel.



Description of goods Item No Specification Unit PCS/CTN N.W./G.W.(KGS) CARTON SIZE(CM)
Depressed grinding disc for inox 80m/s DSG1004016 T27-100X4.0X16MM PC 200 14/15 21*21*25
DSG1006016 T27-100X6.0X16MM PC 200 22/23 22*22*35.7
DSG1154022 T27-115X4.0X22.2MM PC 100 9.5/10.5 24.5*24.5*14.2
DSG1156022 T27-115X6.0X22.2MM PC 100 15/16 24.5*24.5*19.2
DSG1157022 T27-115X7.0X22.2MM PC 100 16.5/17.5 24.5*24.5*22.2
DSG1158022 T27-115X8.0X22.2MM PC 100 18.5/19.5 24.5*24.5*24
DSG1254022 T27-125X4.0X22.2MM PC 100 11.5/12.5 26.5*26.5*14.2
DSG1256022 T27-125X6.0X22.2MM PC 100 17/18 26.5*26.5*19.2
DSG1257022 T27-125X7.0X22.2MM PC 100 18.5/19.5 26.5*26.5*22
DSG1258022 T27-125X8.0X22.2MM PC 100 23/22 26.5*26.5*24
DSG1504022 T27-150X4.0X22.2MM PC 100 18.5/19.5 32*32*14.2
DSG1506022 T27-150X6.0X22.2MM PC 100 24/25 32*32*19.2
DSG1507022 T27-150X7.0X22.2MM PC 60 27/28 32*32*13.5
DSG1508022 T27-150X8.0X22.2MM PC 60 20/19 32*32*15.5
DSG1804022 T27-180X4.0X22.2MM PC 60 14/15 37*19*17.7
DSG1806022 T27-180X6.0X22.2MM PC 60 22/23 37.5*19*22.7
DSG1807022 T27-180X7.0X22.2MM PC 30 12/13 37.5*19*13.5
DSG1808022 T27-180X8.0X22.2MM PC 60 28/29 40*30*20
DSG2304022 T27-230X4.0X22.2MM PC 30 10.5/11.5 24*24*17.7
DSG2306022 T27-230X6.0X22.2MM PC 30 17/18 24*24*22.7
DSG2307022 T27-230X7.0X22.2MM PC 30 19/20 24*24*27
DSG2308022 T27-230X8.0X22.2MM PC 30 22/23 25*24.5*30
