Iinverter Parts Dc Ac Inverter Plasma Cutter Inverter 5kw Solar Inverter Inverter 2000 Watt
Price:
$73-$75
MOQ:
1pcs
Delivery Time:
15-20days
Brand:
SUG
Product Description
Iinverter Parts Dc Ac Inverter Plasma Cutter Inverter 5kw Solar Inverter Inverter 2000 Watt
Charge for the lead acid battery. It means that when there is no grid power input, the grid that inverter needs is from battery. When there is grid power, the grid that inverter needs is from AC grid and at the same time the inverter will charge for the battery. When the grid power is cut off, the output will switch to battery automatically.
| Model | SGPC500A-121 | SGPC500A-122 | SGPC500A-241 | SGPC500A-242 | SGPC500A-481 | SGPC500A-482 |
| Rated Power | 500W | |||||
| Surge Power | 1000W(few seconds) | |||||
| Input Voltage | 12VDC | 24VDC | 48VDC | |||
| Output Voltage | 110VAC±5% | 220VAC±5% | 110VAC±5% | 220VAC±5% | 110VAC±5% | 220VAC±5% |
| USB Port | 5V 1A | |||||
| Frequency | 50Hz±3 or 60Hz±3 | |||||
| Output Waveform | Pure Sine Wave | |||||
| Soft Start | YES | |||||
| Charging Current | 10/20/30A optional | |||||
| Priority | City Power First Priority | |||||
| Transfer Time | 4ms | |||||
| Cooling Way | Intelligent Cooling Fan | |||||
| Protection | Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit, Reverse Polarity | |||||
| Working Temperature | -10ºC - +50ºC | |||||
| Net Dimension | 36.2*16.5*8.7cm (L×W×H) | |||||
| Inner Box Dimension | 45.6*20.6*12.2cm(L×W×H) | |||||
| Meas./Ctn | 52*47.5*38cm/4 pcs | |||||
| N.W./Unit | 4kg | |||||
| G.W./Ctn | 19KGS | |||||
| Packing | Carton | |||||
| Warranty | 1 Years | |||||
