SS304 SS316 DIN2632 Pn10 Socket Weld Pipe Flanges Sch10 Sch40 Sch80

Price Negotiable

Price: US $5.00 / Piece

MOQ: 1 Piece

Delivery Time: 7-14 work days

Brand: ST

Product Description

Sch10 Sch40 Sch80 Stainless Steel SS304 SS316 Standard DIN 2632 Pn10 Weld Neck Pipe Socket Weldig Flange

Product Description

Steel Flanges
Flange Type	Weld Neck Flange, Socket Weld Flange, Slip On Flange, Blind Flange, Thread Flange, Lap Joint Flange, Plate Flange, Orifice Flange, Spectacle Flange, Figure 8 Flange, Paddle Blank, Paddle Spacer, Anchor Flange, Single Blind, Ring Spacer, Reducing Socket Weld flange, Reducing Weld Neck flange, Long Weld Neck Flange SAE Flanges, Hydraulic Flanges, Customized Flanges with drawing.
Material	Carbon steel	A105, A105N, ST37.2, 20#, 35#, C40, Q235, A350 LF2 CL1/CL2, A350 LF3 CL1/CL2, A694 F42, F46, F50, F60, F65, F70, A516 Gr.60, Gr.65, Gr.70
	Alloy steel	A182 F11, A182 F22
	Austenitic stainless steel	A182 F304/304L, F316L, A182 F316H, F310, F321, F321H, F347, F347H
	Duplex stainless steel	A182 F51
	Super Duplex stainless steel	A182 F53, A182 F55, A182 F60
	Nickel alloy	Nickel 200, Nickel 201
	Titanium alloy	Titan Gr.1, Titan Gr.2
	Hastelloy	Hastelloy C-276, Hastelloy C-22, Hastelloy C-4
	Inconel	Inconel 600, Inconel 625, Inconel 800, Inconel 800H
	Monel	Monel 400, Monel K500
Size	DN15 - DN3000
Pressure	Class 150# - 2500#, PN 2.5- PN40, JIS 5K - 20K, 3000PSI, 6000PSI
Connection Way	Flat Face (FF), Raised Face (RF), Ring Joint (RTJ), MFM, TG
Standard	ASME, ANSI, DIN, EN, BS, JIS, GB, AWWA, API, SAE, GOST, MSS
Technical	Forged
Package	Plywood Case/ Wooden Case/ Customized Package
Brand	Shengtian
Certificates	API, ISO, PED, EC, EU
