754060 3.7 V Lithium Polymer Battery 1800mAh Lipo Battery Single Cell with PCM
Price:
negotiable
MOQ:
1000pcs
Delivery Time:
28 days
Brand:
Unitech
Product Description
China Factory Wholesale 754060 3.7V 1800mAh Lipo Battery Single Cell with PCM
Lipo battery Specification:
| Product Name | 754060 1800mAh 3.7V lipo battery | |
| Battery Type | Lithium Polymer battery | |
| Power Wh: | 6.66Wh | |
| Accembly Composed Type | 1S/ 1 cell | |
| Nominal Capacity | 1800 mAh | @0.2C discharge |
| Nominal Voltage | 3.7 V | |
| Charge Voltage | 4.2±0.12 V | |
| Cut-off Voltage | 3.0 V | |
| Standard charge Current | 360 mA | @0.2C charge |
| Max. charge current | 1800 mA | @1C charge |
| Standard Discharge Current | 360 mA | @0.2C discharge |
| Max. Discharge Current | 1800 mA | @1C discharge |
| Resistance | ＜100 mΩ | |
| Cycle Life: | Over 500 times | |
| Weight (Approx.) | 32 g | |
| Dimensions(T.W.L.) | 7.5*40*60 (mm) | |
| Charge Temperature | 0 ~ 45℃ | |
| Discharge Temperature | -10 ~ 60℃ | |
| Storage Temperature | 0~35℃ | Less than one month |
| 0~25℃ | More than one month | |
Batteries discharge curve:
Battery Application:
