Safety A Grade Quality 402535 3.7V Lipo 320mAh Lipo Rechargeable Battery
Price:
negotiable
MOQ:
1000pcs
Delivery Time:
25 days
Brand:
Unitech
Product Description
Safety A Grade Quality 402535 3.7V Lipo 320mAh Lipo Rechargeable Battery
Lipo battery Specification:
| Product Name | 402535 320mAh Lipo battery | |
| Battery Type | Lithium polymer battery | |
| PCM | Available | |
| Accembly Composed Type | 1S1p/ 1 cell | |
| Nominal Capacity | 320 mAh | @0.2C discharge |
| Nominal Voltage | 3.7 V | |
| Charge Voltage | 4.2±0.12 V | |
| Cut-off Voltage | 3.0 V | |
| Standard charge Current | 160mA | @0.5C charge |
| Max. charge current | 320 mA | @1C charge |
| Standard Discharge Current | 160 mA | @0.5C discharge |
| Max. Discharge Current | 320 mA | @1C discharge |
| Resistance | ＜100 mΩ | |
| Cycle Life: | Over 500 times | |
| Weight (Approx.) | 6 g | |
| Dimensions(T.W.L.) | 4.0*25*35 (mm) | |
| Charge Temperature | 0 ~ 45℃ | |
| Discharge Temperature | -20 ~ 60℃ | |
| Storage Temperature | -10~40℃ | Less than one month |
| 0~30℃ | More than one month | |
| Protection Function(PCM) | Over charge, Over discharge, Over load, Short Circuit |
|
| Warranty | 12 Months | |
OEM & ODM service :
(1) Design and produce as customer's requirements ,our R&D team will provide best solutions for you .
(2) Optional for battery voltage / capacity , assemble as your requirements .
(3) Optional for battery size ,we design as your device space ,or recommend suitable models .
(4) Optional for wires / connectors .
(5) Battery is a special goods , we promise use A grade cells and PCM for ensure safety .
Battery package:
The typical application fields of lipo battery:
