42mm 2 phase hybrid stepper motor NEMA17 Uni-Polar 1.8 step motor

Product description of hybrid stepper motor

• 1. Online testing of technical parameters to ensure the consistency of data product parameters
• 2. The material is selected from well-known manufacturers at home and abroad. The advantages are light weight, good heat dissipation performance, good thermal conductivity, die-casting, good plasticity, higher elongation than iron, low noise, good motion stability, the disadvantages are high price, low hardness
• 3. Stepper motors are economical, accurate, and easy to control, and they can operate reliably in a variety of environments (depending on the level of protection IP chosen) preferably in machines with additional enclosures or in clean environments
• Forward/Reverse Rotation,Pause and Hold
• 4.The forward /reverse rotation of the stepping motor can be controlled by the input sequence of the controlled electric pulses.
• In the case of the a stepping motor lock(the motor winding is energized,there is no external electric pulse command),the stepping motor can still maintain a certain torque output.
• 5. Mechanical size 100% meet the requirements, to ensure that there is no greater error in the use process

Quality control process:

•  Incoming inspection: The inspection shall be conducted according to the Requirements of the Incoming Inspection Specification or the product drawing
•  Monitoring and measurement of production process (self-inspection - inspection - batch production)
•  Final inspection and test
•  All inspectors must be trained and then put on duty
•
• . Nonconforming products shall be executed in accordance with Nonconforming Product Control Procedures
• Raw material inspection
• Inspecting according to the standard of testing raw material or the drawing
• Monitoring and measurement in production process
• Self checking-tested by QC-Batches production
• Final checking and make experiment
• All products should be through testing by the professional equipment

• Stepper Motor Control by Varying Clock Pulses

  Stepper motor control circuit is a simple and low-cost circuit, mainly used in low power applications. The circuit is shown in the figure,



  A stepper motor is an electromechanical device it converts electrical power into mechanical power. Also, it is a brushless, synchronous electric motor that can divide a full rotation into an expansive number of steps. The motor’s position can be controlled accurately without any feedback mechanism, as long as the motor is carefully sized to the application. Stepper motors are similar to switched reluctance motors.



  The stepper motor uses the theory of operation for magnets to make the motor shaft turn a precise distance when a pulse of electricity is provided. The stator has eight poles, and the rotor has six poles. The rotor will require 24 pulses of electricity to move the 24 steps to make one complete revolution. Another way to say this is that the rotor will move precisely 15° for each pulse of electricity that the motor receives.



Operation of Stepper Motor:

Stepper motors operate differently from DC brush motors, which rotate when voltage is applied to their terminals. Stepper motors, on the other hand, effectively have multiple toothed electromagnets arranged around a central gear-shaped piece of iron. The electromagnets are energized by an external control circuit, for example, a microcontroller.

Specifications
